Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R1543 1-249-425-11 CARBON 4.7K 5% 1/4W
R1544 1-249-417-11 CARBON 1K 5% 1/4W
R1545 1-249-437-11 CARBON 47K 5% 1/4W
R1546 1-249-437-11 CARBON 47K 5% 1/4W
R1547 1-249-437-11 CARBON 47K 5% 1/4W
R1548 1-249-437-11 CARBON 47K 5% 1/4W
R1551 1-247-863-91 CARBON 22K 5% 1/4W
(GR7: EA4, SAF, TH)
R1551 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R1552 1-249-417-11 CARBON 1K 5% 1/4W
R1553 1-249-426-11 CARBON 5.6K 5% 1/4W
R1554 1-247-840-00 CARBON 2.4K 5% 1/4W
R1555 1-247-863-91 CARBON 22K 5% 1/4W
(GR7: EA4, SAF, TH)
R1555 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R1556 1-249-421-11 CARBON 2.2K 5% 1/4W
R1557 1-249-428-11 CARBON 8.2K 5% 1/4W
< VARIABLE RESISTOR >
RV1501 1-238-598-11 RES, ADJ, CARBON 2.2K
RV1551 1-238-598-11 RES, ADJ, CARBON 2.2K
< RELAY >
RY141 1-755-141-11 RELAY (D60/RX70: US, CND)
RY141 1-755-126-11 RELAY (EXCEPT D60/RX70: US, CND)
< TERMINAL >
TM131 1-537-925-41 TERMINAL BOARD (SPEAKER)
TM132 1-537-925-41 TERMINAL BOARD (SURROUND SPEAKER)
(D60/RX70: US, CND)
< VIBRATOR >
X301 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
X302 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
MOTOR BOARD
************
(Included in AUDIO BOARD, COMPLETE)
< CAPACITOR >
C651 1-161-494-00 CERAMIC 0.022uF 25V
************************************************************
MOTOR (TURN)MOTOR (SLIDE)MOTOR
MAIN
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-987-63 DIODE 1N4148M
D805 8-719-987-63 DIODE 1N4148M
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE DET)
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-010-23 DIODE UZ-3.6BSB
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
