– 107 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC601 8-759-446-27 IC TMP87CH75F-6543
IC602 8-759-332-18 IC GP1U27XB
< INDUCTOR >
L601 1-408-117-00 INDUCTOR 10uH
< TRANSISTOR >
Q601 8-729-118-00 TRANSISTOR 2SB1116-L
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-119-78 TRANSISTOR 2SC403SP-51
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q606 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q607 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q608 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R601 1-247-903-00 CARBON 1M 5% 1/4W
R602 1-247-807-31 CARBON 100 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-247-843-11 CARBON 3.3K 5% 1/4W
R609 1-247-843-11 CARBON 3.3K 5% 1/4W
R610 1-247-807-31 CARBON 100 5% 1/4W
R611 1-247-807-31 CARBON 100 5% 1/4W
R612 1-249-429-11 CARBON 10K 5% 1/4W
R615 1-249-429-11 CARBON 10K 5% 1/4W
R616 1-249-429-11 CARBON 10K 5% 1/4W
R617 1-249-407-11 CARBON 150 5% 1/4W
R619 1-249-401-11 CARBON 47 5% 1/4W
R620 1-249-419-11 CARBON 1.5K 5% 1/4W
R621 1-249-419-11 CARBON 1.5K 5% 1/4W
R622 1-249-401-11 CARBON 47 5% 1/4W
R623 1-249-403-11 CARBON 68 5% 1/4W
R624 1-247-807-31 CARBON 100 5% 1/4W
R625 1-249-407-11 CARBON 150 5% 1/4W
R626 1-249-407-11 CARBON 150 5% 1/4W
R627 1-247-815-91 CARBON 220 5% 1/4W
(GR7: EA4, SAF, TH)
R627 1-249-409-11 CARBON 220 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R628 1-249-411-11 CARBON 330 5% 1/4W
R629 1-249-413-11 CARBON 470 5% 1/4W
R630 1-249-415-11 CARBON 680 5% 1/4W
R631 1-249-417-11 CARBON 1K 5% 1/4W
R632 1-249-419-11 CARBON 1.5K 5% 1/4W
R633 1-249-421-11 CARBON 2.2K 5% 1/4W
R634 1-249-419-11 CARBON 1.5K 5% 1/4W
R635 1-249-401-11 CARBON 47 5% 1/4W
R636 1-249-403-11 CARBON 68 5% 1/4W
R638 1-247-826-00 CARBON 620 5% 1/4W
R639 1-249-411-11 CARBON 330 5% 1/4W
R640 1-249-413-11 CARBON 470 5% 1/4W
R641 1-249-415-11 CARBON 680 5% 1/4W
R642 1-249-417-11 CARBON 1K 5% 1/4W
R643 1-249-419-11 CARBON 1.5K 5% 1/4W
R644 1-249-421-11 CARBON 2.2K 5% 1/4W
R645 1-249-419-11 CARBON 1.5K 5% 1/4W
R646 1-249-401-11 CARBON 47 5% 1/4W
R647 1-249-403-11 CARBON 68 5% 1/4W
R648 1-247-807-31 CARBON 100 5% 1/4W
R649 1-249-407-11 CARBON 150 5% 1/4W
R651 1-249-407-11 CARBON 150 5% 1/4W
R652 1-247-815-91 CARBON 220 5% 1/4W
(GR7: EA4, SAF, TH)
R652 1-249-409-11 CARBON 220 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R653 1-249-411-11 CARBON 330 5% 1/4W
R654 1-249-413-11 CARBON 470 5% 1/4W
R655 1-249-415-11 CARBON 680 5% 1/4W
R656 1-249-417-11 CARBON 1K 5% 1/4W
R657 1-249-419-11 CARBON 1.5K 5% 1/4W
R658 1-249-434-11 CARBON 27K 5% 1/4W
R659 1-247-843-11 CARBON 3.3K 5% 1/4W
R661 1-249-419-11 CARBON 1.5K 5% 1/4W
R663 1-249-429-11 CARBON 10K 5% 1/4W
R664 1-249-421-11 CARBON 2.2K 5% 1/4W
R665 1-247-887-00 CARBON 220K 5% 1/4W
R666 1-249-421-11 CARBON 2.2K 5% 1/4W
R667 1-249-409-11 CARBON 220 5% 1/4W
R668 1-249-409-11 CARBON 220 5% 1/4W
R671 1-247-815-91 CARBON 220 5% 1/4W
(GR7: EA4, SAF,TH)
R671 1-249-409-11 CARBON 220 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R672 1-247-815-91 CARBON 220 5% 1/4W
(GR7: EA4, SAF, TH)
R672 1-249-409-11 CARBON 220 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R673 1-247-807-31 CARBON 100 5% 1/4W
R674 1-247-807-31 CARBON 100 5% 1/4W
R675 1-247-807-31 CARBON 100 5% 1/4W
R676 1-247-807-31 CARBON 100 5% 1/4W
PANEL
