Sony HCD-GR7 - Page 84

– 109 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
POWER AMP
C811 1-130-493-00 MYLAR 0.068uF 5% 50V
C812 1-130-493-00 MYLAR 0.068uF 5% 50V
C814 1-162-306-11 CERAMIC 0.01uF 20% 16V
C841 1-126-925-11 ELECT 470uF 20% 10V
C851 1-124-720-11 ELECT 4.7uF 20% 35V
(EXCEPT D60/RX70: US, CND)
C851 1-126-963-11 ELECT 4.7uF 20% 50V
(D60/RX70: US, CND)
C852 1-162-286-21 CERAMIC 220PF 10% 50V
(GR7: EA4, SAF, TH)
C852 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT GR7: EA4, SAF, TH)
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-126-965-11 ELECT 22uF 20% 50V
C861 1-130-493-00 MYLAR 0.068uF 5% 50V
C862 1-130-493-00 MYLAR 0.068uF 5% 50V
C901 1-104-482-11 ELECT 4700uF 20% 63V
(D60/RX70: US, CND)
C901 1-126-974-11 ELECT 3300uF 20% 50V
(EXCEPT D60/RX70: US, CND)
C902 1-130-777-00 FILM 0.1uF 10% 100V
(D60/RX70: US, CND)
C902 1-136-165-00 FILM 0.1uF 5% 50V
(EXCEPT D60/RX70: US, CND)
C951 1-104-482-11 ELECT 4700uF 20% 63V
(D60/RX70: US, CND)
C951 1-126-974-11 ELECT 3300uF 20% 50V
(EXCEPT D60/RX70: US, CND)
C952 1-130-777-00 FILM 0.1uF 10% 100V
(D60/RX70: US, CND)
C952 1-136-165-00 FILM 0.1uF 5% 50V
(EXCEPT D60/RX70: US, CND)
< CONNECTOR >
CN801 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-987-63 DIODE 1N4148M
D841 8-719-987-63 DIODE 1N4148M
D842 8-719-987-63 DIODE 1N4148M
D851 8-719-987-63 DIODE 1N4148M
D901 8-719-028-23 DIODE D3SBA20-4101
(RX70: AEP, AED, CIS, EE, G, UK)
D901 8-719-510-68 DIODE D5SBA20F01
(D60/GR7/GR7J/RX70: US, CND)
< IC >
IC801 8-749-900-34 IC STK-4182MK2 (GR7/GR7J)
IC801 8-749-920-09 IC STK-4152MK2K
(RX70: AEP, AED, CIS, EE, G, UK)
IC801 8-749-922-65 IC STK-4221MK2 (D60/RX70: US, CND)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-900-36 TRANSISTOR DTC124ES
(D60/GR7/GR7J/RX70: US, CND)
Q832 8-729-119-78 TRANSISTOR 2SC403SP-51
(D60/GR7/GR7J/RX70: US, CND)
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W
(D60/RX70: US, CND)
R803 1-249-415-11 CARBON 680 5% 1/4W
(EXCEPT D60/RX70: US, CND)
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-260-103-11 CARBON 2.2K 5% 1/2W
(RX70: AEP, AED, CIS, EE, G, UK)
R805 1-260-105-11 CARBON 3.3K 5% 1/2W
(GR7/GR7J)
R805 1-260-107-11 CARBON 4.7K 5% 1/2W
(D60/RX70: US, CND)
R806 1-260-103-11 CARBON 2.2K 5% 1/2W
(RX70: AEP, AED, CIS, EE, G, UK)
R806 1-260-105-11 CARBON 3.3K 5% 1/2W
(GR7/GR7J)
R806 1-260-107-11 CARBON 4.7K 5% 1/2W
(D60/RX70: US, CND)
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-208-601-11 WIREWOUND 0.1 10% 2W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-247-863-91 CARBON 22K 5% 1/4W
(GR7: EA4, SAF, TH)
R812 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-099-11 CARBON 1K 5% 1/2W
(EXCEPT D60/RX70: US, CND)
R814 1-260-105-11 CARBON 3.3K 5% 1/2W
(D60/RX70: US, CND)
R816 1-260-099-11 CARBON 1K 5% 1/2W
(EXCEPT D60/RX70: US, CND)
R816 1-260-105-11 CARBON 3.3K 5% 1/2W
(D60/RX70: US, CND)
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R831 1-249-441-11 CARBON 100K 5% 1/4W
(D60/GR7/GR7J/RX70: US, CND)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
