Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TCB
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q5 8-729-424-08 TRANSISTOR MUN2111T1
Q9 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q11 8-729-421-22 TRANSISTOR MUN2211T1
Q12 8-729-421-22 TRANSISTOR MUN2211T1
Q13 8-729-421-22 TRANSISTOR MUN2211T1
Q14 8-729-421-22 TRANSISTOR MUN2211T1
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-216-049-91 CHIP 1K 5% 1/10W
R22 1-216-049-91 CHIP 1K 5% 1/10W
R23 1-216-049-91 CHIP 1K 5% 1/10W
R24 1-216-025-91 CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-417-11 CARBON 1K 5% 1/4W
R28 1-249-417-11 CARBON 3.3K 5% 1/4W
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 CHIP 330 5% 1/8W
R31 1-216-025-91 CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W
R33 1-249-425-11 CARBON 4.7K 5% 1/4W
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 CHIP 4.7K 5% 1/8W
R36 1-216-025-91 CHIP 100 5% 1/10W
CF2 1-760-393-11 FILTER, CERAMIC
CF3 1-760-393-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< DIODE >
D21 8-719-976-99 DIODE UDZ-TE-17-5.1B
D41 8-719-016-74 DIODE 1SS352-TPH3
< FRONTEND >
FE1 1-693-357-11 FRONT END (4 GANG)
FE2 1-233-514-11 ENCAPSULATED COMPONENT
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< CHIP CONDUCTOR >
JR2 1-216-295-00 CONDUCTOR, CHIP (2012)
JR6 1-216-295-00 CONDUCTOR, CHIP (2012)
JR8 1-216-295-00 CONDUCTOR, CHIP (2012)
JR9 1-216-295-00 CONDUCTOR, CHIP (2012)
JR45 1-216-295-00 CONDUCTOR, CHIP (2012)
JR46 1-216-296-00 CONDUCTOR, CHIP (3216)
JR47 1-216-295-00 CONDUCTOR, CHIP (2012)
JR48 1-216-295-00 CONDUCTOR, CHIP (2012)
JR49 1-216-296-00 CONDUCTOR, CHIP (3216)
JR51 1-216-295-00 CONDUCTOR, CHIP (2012)
JR52 1-216-295-00 CONDUCTOR, CHIP (2012)
JR53 1-216-296-00 CONDUCTOR, CHIP (3216)
JR54 1-216-295-00 CONDUCTOR, CHIP (2012)
< JUMPER RESISTOR >
JW4 1-249-413-11 CARBON 470 5% 1/4W
JW5 1-249-413-11 CARBON 470 5% 1/4W
< COIL >
L2 1-414-142-11 INDUCTOR, MICRO 1uH
L3 1-410-521-11 INDUCTOR, MICRO 100uH
L4 1-410-515-11 INDUCTOR, MICRO 33uH
L41 1-407-500-00 MICRO INDUCTOR 4.7mH
