Sony HCD-GR7 - 1. CORRECTION

– 2 –
q or___ (Under line): indicates changed portion.
Ref. No. Part No. Description Remark
106 1-233-514-11 ENCAPSULATED COMPONENT
(RX70: CIS, EE)
Page Incorrect Correct
CD MECHANISM DECK SECTION CD MECHANISM DECK SECTION
3 two screws
(BVTP3 × 8)
2 flat wire
(CN202)
1 two connectors
(CN203, 204)
3 three screws
(BVTP3 × 8)
2 flat wire
(CN202)
1 two connectors
(CN203, 204)
23
87
C654 1-162-294-31 CERAMIC 0.001uF 10% 50V
C654 1-162-294-31 CERAMIC 0.001MF 10% 50V
106
k
o
1. CORRECTION
Ref. No. Part No. Description Remark
* 106 A-4303-570-A TCB BOARD, COMPLETE (RX70: EE, CIS)
