HCD-GTR333/GTR555/GTR777/GTR888
10
2-8. BACK PANEL SECTION
2-9. 2CH DAMP BOARD, 3CH DAMP BOARD, 4CH DAMP BOARD
9 one screw
(+BVTP 3 u 12)
0 back panel section
6 one screws
(+BVTP 3 u 12)
7 one screws
(+BVTP 3 u 8)
2 four screws
(+BVTP 3 u 8)
4 cover, fan
5 fan, DC
1 CN4004 (3P)
3 two screws
(+BVTP 3 u 8)
(for HCD-GTR777/ HCD-GTR888)
8 one screws
(+BVTP 3 u 8)
(for HCD-GTR555/HCD-GTR777/HCD-GTR888)
3 heatsink (4CH)
2 three brackets
(heatsink plug)
7 six screws
(+BVTP 3 u 8)
5 CN2 (6P)
4 sheet (thermal)
4 sheet (thermal)
6 CN3 (5P)
8 3CH DAMP board
4CH DAMP board
1 three screws
(+BVTT 3 u 12 (S))
1 three screws
(+BVTT 3 u 12 (S))
A
B
C
B
C
B
C
A
3 heatsink (2CH)
2 two brackets
(heatsink plug)
7 four screws
(+BVTP 3 u 8)
5 CN2 (6P)
6 CN3 (5P)
8 2CH DAMP board
A
A
(for HCD-GTR333) (for HCD-GTR555/HCD-GTR777/HCD-GTR888)
Ver. 1.1
