HCD-GTX66/GTX77
2-3. TUNER P
ACK
2-4. CD BLOCK SECTION
3
tuner pack
2
wire (flat type) (9 core)
(CN1)
1
two
screws
(+BVTP 3
×
8)
1
screw
(+BVTP 3
×
8)
5
three
screws
(+BVTP 3
×
12)
2
lug
3
tapping screw
4
tapping screw
6
wire (flat type) (13 core)
(CN701)
qs
CD bloc
k section
7
9
wire (flat type) (21 core)
(CN5053)
0
CN903 (5P)
qa
CN901 (2P)
8
wire (flat type) (27 core)
(CN5051)
