23
HCD-HDX265/HDX266/HDX267W/HDX465/HDX466/HDX665
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DIAT CON BOARD
**************
< CONNECTOR >
CN1806 1-770-382-11 CONNECTOR, BOARD TO BOARD 12P
CN1809 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< JUMPER RESISTOR >
JR001 1-216-296-11 SHORT CHIP 0
JR002 1-216-296-11 SHORT CHIP 0
JR003 1-216-864-11 SHORT CHIP 0
JR004 1-216-296-11 SHORT CHIP 0
JR005 1-216-296-11 SHORT CHIP 0
JR006 1-216-296-11 SHORT CHIP 0
JR007 1-216-864-11 SHORT CHIP 0
JR008 1-216-296-11 SHORT CHIP 0
JR009 1-216-864-11 SHORT CHIP 0
JR010 1-216-864-11 SHORT CHIP 0
************************************************************
A-1221-025-A DMPORT BOARD, COMPLETE
************************
< CAPACITOR >
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C212 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C213 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C220 1-128-995-21 ELECT CHIP 100uF 20% 10V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C223 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C229 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C230 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C231 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C232 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C233 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C234 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C235 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C236 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C237 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C238 1-126-395-11 ELECT CHIP 22uF 20% 16V
C239 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C240 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C241 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN201 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN203 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
CN204 1-817-615-21 CONNECTOR BOARD TO BOARD 18P
(DMPORT)
< IC >
IC201 6-705-308-01 IC SI-3010KM-TL
IC202 8-759-710-97 IC NJM4565M-D
< COIL >
L200 1-469-525-11 INDUCTOR 10uH
< RESISTOR >
R203 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R208 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R214 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R215 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R221 1-216-821-11 METAL CHIP 1K 5% 1/10W
R222 1-216-840-11 METAL CHIP 39K 5% 1/10W
R223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R224 1-216-864-11 SHORT CHIP 0
R227 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R228 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R229 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R230 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R231 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R232 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R237 1-216-864-11 SHORT CHIP 0
R238 1-216-864-11 SHORT CHIP 0
R239 1-216-864-11 SHORT CHIP 0
R240 1-216-809-11 METAL CHIP 100 5% 1/10W
R241 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
EN BOARD
*********
< CAPACITOR >
C910 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
DIAT CON
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
AUS: Australian model
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque 9
contiennent des informations confidentielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé et /
ou réparé.
When indicating parts by reference number,
please include the board.
DMPORT
3. ELECTRICAL PARTS LIST
EN
