HCD-MX500i/MX550i
5
HOW TO OPEN THE TRAY WHEN POWER SWITCH TURN OFF
MAIN, BD96/BD96U AND SP BOARDS SERVICE POSITION
bottom side
1 Insert the hard metal fittings of L character type in the
hole of the chassis, and push the lever in the direction
of the arrow.
SP board
MAIN board
BD96 board (Canadian)
BD96U board (Except Canadian)
To Next Page
