Pin No. Pin Name I/O Description
72 VDD4 — Power suply terminal(+5V)
73 9818_PDN O PDN signal output to the Audio Dac
74 9818_RESET O Reset signal output to the Audio Dac
75 NC75 — Not used
76 NC76 — Not used
77 16:9/4:3 O Output signal of TV MODE change
78 TV_MODE O Output signal of TV MODE
79 R/G/B_VIDEO O R/G/B signal output
80 NC80 — Not used
81 NC81 — Not used
82 NC82 — FAN ON/OFF Control input(SB200)
83 NC83 — Not used
84 NC84 — Not used
85 505_PDN O Standby signal output to the Audio Amp
86 NC86 — Not used
87 NC87 — Not used
88 9818_CLK O Clock signal output to the Audio Dac
89 VSS2 — Ground terminal
90 VDD2 — Power suply terminal(+5V)
91 9818_SDA O SDA signal output to the Audio Dac
92 NC92 — Not used
93 NC93 — Not used
94 NC94 — Not used
95 DATA1 O DATA1 signal output terminal(Not Used)
96 DATA0 O DATA0 signal output terminal(Not Used)
97 CLK O Clock signal output terminal(Not Used)
98 DVD_SO O DATA signal output to the Mpeg&Video Process
99 D_SI I DATA signal input from the Mpeg&Video Process
100 D_CK O Clock signal output to the Mpeg&Video Process
