Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 54 —
R434 1-249-425-11 CARBON 4.7K 5% 1/4W F
R435 1-249-425-11 CARBON 4.7K 5% 1/4W F
R436 1-249-417-11 CARBON 1K 5% 1/4W F
R437 1-249-436-11 CARBON 39K 5% 1/4W
R438 1-249-436-11 CARBON 39K 5% 1/4W
R439 1-249-437-11 CARBON 47K 5% 1/4W
R440 1-249-437-11 CARBON 47K 5% 1/4W
R442 1-247-843-11 CARBON 3.3K 5% 1/4W
R447 1-249-411-11 CARBON 330 5% 1/4W
R448 1-249-427-11 CARBON 6.8K 5% 1/4W F
R449 1-249-429-11 CARBON 10K 5% 1/4W
R450 1-249-425-11 CARBON 4.7K 5% 1/4W F
R453 1-249-426-11 CARBON 5.6K 5% 1/4W
R454 1-249-417-11 CARBON 1K 5% 1/4W F
R455 1-247-840-00 CARBON 2.4K 5% 1/4W
R456 1-249-421-11 CARBON 2.2K 5% 1/4W F
R457 1-249-428-11 CARBON 8.2K 5% 1/4W F
R459 1-249-433-11 CARBON 22K 5% 1/4W
R469 1-249-433-11 CARBON 22K 5% 1/4W
R470 1-249-425-11 CARBON 4.7K 5% 1/4W F
R480 1-249-430-11 CARBON 12K 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W F
R705 1-249-438-11 CARBON 56K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R754 1-249-417-11 CARBON 1K 5% 1/4W F
R755 1-249-438-11 CARBON 56K 5% 1/4W
R756 1-249-417-11 CARBON 1K 5% 1/4W F
R855 1-249-417-11 CARBON 1K 5% 1/4W F
R859 1-249-417-11 CARBON 1K 5% 1/4W F
! R861 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
! R862 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
< VARIABLE RESISTOR >
RV401 1-238-598-11 RES, ADJ, CARBON 2.2K
RV451 1-238-598-11 RES, ADJ, CARBON 2.2K
< VIBRATOR >
X101 1-760-489-11 VIBRATOR, CERAMIC 5MHz
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-987-63 DIODE 1N4148M
D805 8-719-987-63 DIODE 1N4148M
< IC >
IC801 8-759-274-09 IC BA6286N
< MOTOR >
M801 A-4672-004-A MOTOR ASSY (SLED)
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
S811 1-473-335-11 ENCODER, ROTARY (BU,TRAY ADDRESS DET)
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
********************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-010-23 DIODE UZ-3.6BSB
< IC >
IC701 8-759-633-65 IC M54641L
< MOTOR >
M701 A-4672-004-A MOTOR ASSY (TURN)
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
* 1-666-004-11 RESISTOR BOARD
***************
< CAPACITOR >
C851 1-164-159-11 CERAMIC 0.1uF 50V
C852 1-164-159-11 CERAMIC 0.1uF 50V
C865 1-126-967-11 ELECT 47uF 20% 10V
< DIODE >
D851 8-719-987-63 DIODE 1N4148M
D852 8-719-987-63 DIODE 1N4148M
< IC >
IC851 8-759-231-58 IC TA7812S
IC852 8-759-231-53 IC TA7805S
IC853 8-759-604-86 IC M5F7807L
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN MOTOR (SLIDE) MOTOR (TURN) RESISTOR
