Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 55 —
< RESISTOR >
! R863 1-212-934-00 FUSIBLE 1 5% 1/2W F
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
* 1-666-007-11 TC (A) BOARD
************
< DIODE >
D207 8-719-058-03 DIODE SEL5423E-TP15 (·)
D208 8-719-058-03 DIODE SEL5423E-TP15 (·)
D209 8-719-058-03 DIODE SEL5423E-TP15 (ª)
D210 8-719-058-03 DIODE SEL5423E-TP15 (ª)
< TRANSISTOR >
Q203 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q204 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R213 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R214 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R215 1-216-077-00 METAL CHIP 15K 5% 1/10W
R230 1-216-033-00 METAL CHIP 220 5% 1/10W
R231 1-216-033-00 METAL CHIP 220 5% 1/10W
R232 1-216-033-00 METAL CHIP 220 5% 1/10W
R233 1-216-033-00 METAL CHIP 220 5% 1/10W
< SWITCH >
S264 1-762-750-11 SWITCH, TACTILE (π)
S265 1-762-750-11 SWITCH, TACTILE (ª)
S266 1-762-750-11 SWITCH, TACTILE (·)
************************************************************
* 1-666-008-11 TC (B) BOARD
************
< JACK >
CNJ105 1-770-402-11 HOUSING, CONNECTOR(PC BOARD)9P
< DIODE >
D201 8-719-058-03 DIODE SEL5423E-TP15 (·)
D202 8-719-058-03 DIODE SEL5423E-TP15 (·)
D203 8-719-058-03 DIODE SEL5423E-TP15 (ª)
D204 8-719-058-03 DIODE SEL5423E-TP15 (ª)
< TRANSISTOR >
Q201 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q202 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R201 1-216-017-91 METAL GLAZE 47 5% 1/10W
R202 1-216-021-00 METAL CHIP 68 5% 1/10W
R224 1-216-033-00 METAL CHIP 220 5% 1/10W
R225 1-216-033-00 METAL CHIP 220 5% 1/10W
R226 1-216-033-00 METAL CHIP 220 5% 1/10W
R227 1-216-033-00 METAL CHIP 220 5% 1/10W
< SWITCH >
S251 1-762-750-11 SWITCH, TACTILE (·)
S252 1-762-750-11 SWITCH, TACTILE (ª)
S253 1-762-750-11 SWITCH, TACTILE (π)
************************************************************
* A-4398-496-A TC PANEL BOARD COMPLETE
************************
< DIODE >
D205 8-719-033-06 DIODE SEL5920A (PAUSE P)
D206 8-719-812-44 DIODE TLO124 (REC)
< TRANSISTOR >
Q219 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q220 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R203 1-216-025-91 METAL GLAZE 100 5% 1/10W
R204 1-216-029-00 METAL CHIP 150 5% 1/10W
R205 1-216-029-00 METAL CHIP 150 5% 1/10W
R206 1-216-033-00 METAL CHIP 220 5% 1/10W
R207 1-216-037-00 METAL CHIP 330 5% 1/10W
R208 1-216-041-00 METAL CHIP 470 5% 1/10W
R209 1-216-045-00 METAL CHIP 680 5% 1/10W
R210 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R211 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R212 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R228 1-216-033-00 METAL CHIP 220 5% 1/10W
R229 1-216-033-00 METAL CHIP 220 5% 1/10W
< SWITCH >
S254 1-762-750-11 SWITCH, TACTILE (0)
S255 1-762-750-11 SWITCH, TACTILE ())
S256 1-762-750-11 SWITCH, TACTILE (DIRECTION MODE)
S257 1-762-750-11 SWITCH, TACTILE (PAUSE P)
S258 1-762-750-11 SWITCH, TACTILE (REC)
S259 1-762-750-11 SWITCH, TACTILE (HI-SPEED DUBBING)
S260 1-762-750-11 SWITCH, TACTILE (CD SYNCHRO)
S261 1-762-750-11 SWITCH, TACTILE (DOLBY NR)
S262 1-762-750-11 SWITCH, TACTILE (0)
S263 1-762-750-11 SWITCH, TACTILE ())
************************************************************
RESISTOR SENSOR TC (A) TC (B) TC PANEL
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
