MISCELLANEOUS
***************
4 1-773-112-11 WIRE (FLAT TYPE) (19 CORE)
5 1-765-325-11 WIRE (FLAT TYPE) (11 CORE)
6 1-773-155-11 WIRE (FLAT TYPE) (21 CORE)
* 10 1-666-009-11 DUMMY BOARD
64 1-773-053-11 WIRE (FLAT TYPE) (17 CORE)
257 1-452-538-11 MAGNET
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-848-379-31 OPTICAL PICK-UP KSS-213B/S-N
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK)(DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE)(DECK B)
M1 A-2004-409-A MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY, SPINDLE
M102 X-4917-504-1 MOTOR ASSY, SLED
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLED)
S811 1-473-335-11 ENCODER, ROTARY (BU,TRAY ADDRESS DET)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#5 7-621-775-00 SCREW +B 2.6X3
#6 7-621-255-15 SCREW +P 2X3
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-623-921-01 RING, RETAINING, CAPSTAN
#12 7-621-775-10 SCREW +B 2.6X4
