Use the MAINTENANCE menu to set the mode.
For details about menu operations, see “Menu Operations”
(page 17).
When the control system connection mode is changed, turn
the power of all devices in the system off and then back on.
To connect in LEGACY mode
Set CNS MODE to LEGACY.
For details, see “CNS SETTINGS (MAINTENANCE menu)”
(page 11).
When a LAN cable will not be connected directly to the unit,
even when building a camera network system using a LAN,
set CNS MODE to LEGACY mode.
To connect in BRIDGE mode
1 Set CNS MODE to BRIDGE.
For details, see “CNS SETTINGS (MAINTENANCE
menu)” (page 11).
2 Configure settings related to TCP/IP.
For details, see “TCP/IP SETTING (MAINTENANCE
menu)” (page 11).
3 Set the IP address of the unit as the “target IP
address” of the MSU or RCP to be connected to the
LAN.
For details, see the operation manual of the MSU or RCP.
BRIDGE mode does not support a multi-camera system.
To connect in MCS mode
In MCS mode, one MSU that can be called the master is
required.
If there are multiple MSUs, set one of them to “master” and the
others to “client.”
1 Set CNS MODE to MCS.
For details, see “CNS SETTINGS (MAINTENANCE
menu)” (page 11).
2 Set CCU NO.
For details, see “CNS SETTINGS (MAINTENANCE
menu)” (page 11).
3 Set MASTER IP ADDRESS.
For details, see “CNS SETTINGS (MAINTENANCE
menu)” (page 11).
4 Configure settings related to TCP/IP.
For details, see “TCP/IP SETTING (MAINTENANCE
menu)” (page 11).
5 Configure the settings of the MSU or RCP to connect
by LAN.
For details, see the operation manual of the MSU or RCP.
• When connecting the RCP to the unit with a CCA-5 cable
and using a LAN cable for the connection device of that
RCP, set CNS MODE to LEGACY mode.
• When connecting the RCP to the camera with a LAN cable
and using a CCA cable for the connection device of that
RCP, set CNS MODE to MCS mode.
• Set CCU NO to a number that is not a duplicate of any of the
CCU device numbers in the system.
Menus used to configure the control system
connection settings
For details about menu operations, see “Menu Operations”
(page 17).
TCP/IP SETTING (MAINTENANCE menu)
IP ADDRESS: Set the IP address to assign to the unit.
SUBNET MASK: Set the subnet mask of the network
environment.
DEFAULT GATEWAY: Set the default gateway of the network
environment if necessary.
CNS SETTINGS (MAINTENANCE menu)
CNS MODE: Set the control system connection mode.
LEGACY: Set the mode to LEGACY mode.
BRIDGE: Set the mode to BRIDGE mode.
MCS: Set the mode to MCS mode.
CCU NO: Set the device number (camera number) of the unit
when using MCS mode. Set a number that is not a
duplicate of any of the CCU device numbers in the
system.
MASTER IP ADDRESS: Set the IP address of the master
device for MCS mode.
Note
Note
Note
Notes
<TCP/IP SETTING> M15 TOP
IP ADDRESS:
0. 0. 0. 0
SUBNET MASK:
0. 0. 0. 0
DEFAULT GATEWAY:
0. 0. 0. 0
SET
<CNS SETTINGS> M16 TOP
CNS MODE : LEGACY
CCU NO : 0
MASTER IP ADDRESS:
0. 0. 0. 0
SET
