29
<VF DETAIL>
03 (U02)
VF DETAIL ON
, OFF
0 to 100%, 25%
CRISP –99 to +99, 0
FREQUENCY 9M, 14M, 18M
FLICKER ON, OFF
AREA 100%, 70%, 60%, 50%, 40%,
30%, 20%, 10%
ZOOM LINK ON
, OFF
0 to 100%, 50%
(5% increments)
COLOR DETAIL ON, OFF
YELLOW, RED, BLUE
PEAK COLOR ON, OFF
CHROMA LEVEL 100%, 50%, 25%, 0%
DYNAMIC FOCUS OFF
, ON, (OFF) (OFF): HD format
<DYNAMIC FOCUS>
04
DYNAMIC FOCUS OFF
, ON, (OFF) (OFF): HD format
FREQUENCY EXTRA-LOW
, LOW, MIDDLE,
HIGH, (AUTO)
Sets the bandwidth of the 4K resolution high-
frequency signal to detect.
(AUTO): Displayed when ZOOM LINK is ON.
ZOOM LINK ON, OFF
MODE1, MODE2, MODE3,
MODE4
Sets characteristics according to the zoom position.
0 to 100%, 50%
(5% increments)
Sets the level at the WIDE position mark.
CRISP 0
to 99% Adjust to eliminate fine portions of the detected signal.
LEVEL LOW
, MIDDLE, HIGH, VERY-
HIGH
Sets the brightness level of the marking signal.
PEAK COLOR OFF, RED, BLUE, GREEN,
BROWN, PURPLE, YELLOW
THRESHOLD 0 to 99% Sets the threshold level for adding color specified
using PEAK COLOR.
COLOR LEVEL 0 to 99%, 50%
Sets the saturation of the color of the PEAK COLOR
indicator.
<FOCUS POSITION
METER1>
05
FOCUS POSITION
METER
OFF
, ON Shows/hides the focus position meter.
NEAR LIMIT 0
to 999 Sets the NEAR edge of the focus position meter.
FAR LIMIT 0 to 999
Sets the FAR edge of the focus position meter.
DIRECTION HORIZONTAL
, VERTICAL Sets the display direction of the focus position meter.
HORIZONTAL: Horizontal display at the top of the
screen.
VERTICAL: Vertical display along the right edge of the
screen.
SIZE NORMAL
, HALF Sets the display size of the focus position meter.
RULED LINE OFF
, ON Shows/hides ruled lines.
INDEX COLOR BLACK, WHITE
Sets the index color.
INDEX WIDTH 1
to 5 Sets the index width.
MARKER WIDTH 1
to 9 Sets the width of the marker axis portion.
CURRENT FOCUS DIST Displays the current focus distance (display only).
OPERATION
Page name
Page No.
Item Settings Description
