30
<FOCUS POSITION
METER2>
06
ADJUSTED SIGN
SENSE 1 to 5, 2
Sets the adjustment sensitivity.
Increasing the value increases the sensitivity.
NAME DISP OFF, 1S, 3S, 5S, ON
Sets whether to show/hide the marker name and sets
the display time.
FRAME DISP OFF, 1S, 3S, 5S, ON
Sets whether to show/hide the adjustment frame and
sets the display time.
FRAME WIDTH 1 to 5, 2
Sets the width of the adjustment frame.
MARKER CONFIG
[REG] MKR1, 2, 3 Execute using ENTER. Registers a marker at the current focus position.
(Cannot be registered here if marker registration has
been assigned to a dedicated switch.)
[DISP] MKR1, 2, 3 OFF
, ON Shows/hides markers.
(Cannot be registered here if marker registration has
been assigned to a dedicated switch.)
[COLOR] MKR1, 2, 3 RED
, GREEN, BLUE, YELLOW,
ORANGE, PURPLE, GRAY,
BLACK, WHITE
Sets the color of triangular parts of the marker.
(Cannot be registered here if marker registration has
been assigned to a dedicated switch.)
[NAME] MKR1, 2, 3 Max. 8 characters
(Default value: MARKER 1 to 3)
Sets the text of the marker name.
See “To specify a character string” (page 19).
[POS] MKR1, 2, 3 0 to 999 Sets the position of the marker.
CURRENT FOCUS DIST Displays the current focus distance (display only).
<FOCUS ASSIST>
07 (U03)
INDICATOR ON, OFF
MODE BOX, B&W, COL
BTM
, LEFT, TOP, RIGHT
LEVEL MIN, 1 to 10, 4
QUICK, SMOOTH
GAIN 0 to 99, 50
OFFSET 0 to 99, 50
AREA MARKER ON, OFF
SIZE SMALL, MIDDLE, LARGE
POSITION LEFT, CENTER
, RIGHT
POSITION H 0 to 99, 50
POSITION V 0 to 99, 50
<ZEBRA>
08 (U08)
ZEBRA ON, OFF
1, 2, 1&2
ZEBRA1
LEVEL 50 to 109%, 70%
WIDTH 0 to 30%, 10%
ZEBRA2 50 to 109%, 100%
OPERATION
Page name
Page No.
Item Settings Description
