32
<EXT I/O>
15
PIN4 OFF
, R-TALLY OUT, G-TALLY
OUT, TALLY OUT, R-TALLY IN,
G-TALLY IN, FOCUS POS
METER, FOCUS POS MKR1,
FOCUS POS MKR2, FOCUS
POS MKR3, FOCUS ASSIST,
SPIRIT LEVEL, VF DETAIL,
ZEBRA, DIGITAL EXTENDER,
5600K, VTR S/S
Function assignment of Assignable pins on EXT I/O
connector.
Note
DIGITAL EXTENDER is enabled only when OUTPUT
FORMAT is HD (excluding HFR).
PIN6 OFF
, R-TALLY OUT, G-TALLY
OUT, TALLY OUT, R-TALLY IN,
G-TALLY IN, FOCUS POS
METER, FOCUS POS MKR1,
FOCUS POS MKR2, FOCUS
POS MKR3, FOCUS ASSIST,
SPIRIT LEVEL, VF DETAIL,
ZEBRA, DIGITAL EXTENDER,
5600K, VTR S/S
PIN7 OFF
, R-TALLY OUT, G-TALLY
OUT, TALLY OUT, R-TALLY IN,
G-TALLY IN, FOCUS POS
METER, FOCUS POS MKR1,
FOCUS POS MKR2, FOCUS
POS MKR3, FOCUS ASSIST,
SPIRIT LEVEL, VF DETAIL,
ZEBRA, DIGITAL EXTENDER,
5600K, VTR S/S
PIN8 OFF
, FOCUS POS METER,
FOCUS POS MKR1, FOCUS
POS MKR2, FOCUS POS MKR3,
FOCUS ASSIST, SPIRIT LEVEL,
VF DETAIL, ZEBRA, DIGITAL
EXTENDER, 5600K, VTR S/S,
MIC IN
Function assignment of Assignable pins on EXT I/O
connector.
(If MIC IN is set for either, MIC IN is also assigned on
the other.)
PIN9 OFF
, FOCUS POS METER,
FOCUS POS MKR1, FOCUS
POS MKR2, FOCUS POS MKR3,
FOCUS ASSIST, SPIRIT LEVEL,
VF DETAIL, ZEBRA, DIGITAL
EXTENDER, 5600K, VTR S/S,
MIC IN
MIC GAIN 20dB, 30dB, 40dB, 50dB, 60dB
MIC +48V ON, OFF
<OPERATOR FILE>
16
READ (USBtCAM) Execute using ENTER. Reads the operator file from a USB drive.
WRITE (CAMtUSB) Execute using ENTER. Writes the current settings of the operator file items to
a USB drive.
PRESET Execute using ENTER. Sets the operator file items to the preset values in
internal memory.
OPERATION
Page name
Page No.
Item Settings Description
