SDI 1 to SDI 4 connector settings
SYSTEM FORMAT SDI OUT
<OUTPUT FORMAT> <SDI OUT>
RESOLUTION FREQUENCY OETF SLOT1/2-OUT SLOT3/4-OUT
Output format Output format
3840×2160 59.94P/50P Other
than SDR
4K/12G/HDR
3840×2160/59.94P Single-Link HD/3G-A/SDR 1920×1080/59.94P
HD/3G-B/SDR 1920×1080/59.94P
HD/1.5G/SDR 1920×1080/59.94i
4K/3G-A/2SI/HDR 3840×2160/59.94P Quad-Link 4K/3G-A/2SI/HDR 3840×2160/59.94P
4K/3G-B/2SI/HDR 3840×2160/59.94P 4K/3G-B/2SI/HDR 3840×2160/59.94P
4K/3G-A/SQD/HDR 3840×2160/59.94P 4K/3G-A/SQD/
HDR
3840×2160/59.94P
4K/3G-B/SQD/HDR 3840×2160/59.94P 4K/3G-B/SQD/
HDR
3840×2160/59.94P
SDR 4K/12G/HDR
3840×2160/59.94P Single-Link HD/3G-A/SDR 1920×1080/59.94P
HD/3G-B/SDR 1920×1080/59.94P
HD/1.5G/SDR 1920×1080/59.94i
4K/3G-A/2SI/HDR 3840×2160/59.94P Quad-Link 4K/3G-A/2SI/SDR 3840×2160/59.94P
4K/3G-B/2SI/HDR 3840×2160/59.94P 4K/3G-B/2SI/SDR 3840×2160/59.94P
4K/3G-A/SQD/SDR 3840×2160/59.94P 4K/3G-A/SQD/
SDR
3840×2160/59.94P
4K/3G-B/SQD/HDR 3840×2160/59.94P 4K/3G-B/SQD/
SDR
3840×2160/59.94P
29.97P/25P Other
than SDR
4K/6G/HDR
3840×2160/29.97P Single-Link HD/1.5G/SDR 1920×1080/
29.97PsF
4K/3G-B/2SI/HDR 3840×2160/29.97P Dual-Link HD/1.5G/SDR 1920×1080/
29.97PsF
4K/3G-B/SQD/HDR 3840×2160/
29.97PsF
HD/1.5G/SDR 1920×1080/
29.97PsF
4K/1.5G/SQD/HDR 3840×2160/
29.97PsF
Quad-Link 4K/1.5G/SQD/HDR 3840×2160/
29.97PsF
SDR 4K/6G/SDR
3840×2160/29.97P Single-Link HD/1.5G/SDR 1920×1080/
29.97PsF
4K/3G-B/2SI/HDR 3840×2160/29.97P Dual-Link HD/1.5G/SDR 1920×1080/
29.97PsF
4K/3G-B/SQD/HDR 3840×2160/
29.97PsF
HD/1.5G/SDR 1920×1080/
29.97PsF
4K/1.5G/SQD/HDR 3840×2160/
29.97PsF
Quad-Link 4K/1.5G/SQD/HDR 3840×2160/
29.97PsF
23.98P/24P Other
than SDR
4K/6G/HDR
3840×2160/23.98P Single-Link HD/1.5G/SDR 1920×1080/
23.98PsF
4K/3G-B/2SI/HDR 3840×2160/23.98P Dual-Link HD/1.5G/SDR 1920×1080/
23.98PsF
4K/3G-B/SQD/HDR 3840×2160/
23.98PsF
HD/1.5G/SDR 1920×1080/
23.98PsF
4K/1.5G/SQD/HDR 3840×2160/
23.98PsF
Quad-Link 4K/1.5G/SQD/HDR 3840×2160/
23.98PsF
SDR 4K/6G/SDR
3840×2160/23.98P Single-Link HD/1.5G/SDR 1920×1080/
23.98PsF
4K/3G-B/2SI/SDR 3840×2160/23.98P Dual-Link HD/1.5G/SDR 1920×1080/
23.98PsF
4K/3G-B/SQD/HDR 3840×2160/
23.98PsF
HD/1.5G/SDR 1920×1080/
23.98PsF
4K/1.5G/SQD/HDR 3840×2160/
23.98PsF
Quad-Link 4K/1.5G/SQD/HDR 3840×2160/
23.98PsF
