Menu List
DIAGNOSIS Menu
This menu is only for viewing and no setting is made using
this menu.
Menu page No. Item Indication Remarks
<OPTICAL LEVEL> D01 CCU→CAM GREEN, YELLOW, RED, NG, NO
SIGNAL
With CCU connected only
CAM→CCU GREEN, YELLOW, RED, NG, NO
SIGNAL
With CCU connected only
<BOARD STATUS> D02 ROM Vx.xxx ROM version
OHB OK, NG
DPR OK, NG
VDA OK, NG
DAP OK, NG
AU OK, NG
AT OK, NG
PS OK, NG
SDI OK, NG
<PLD VERSION> D03 TG Vx.xxx
VDA Vx.xxx
DAP Vx.xxx
AT Vx . x x x
SDI Vx.xxx
<ROM VERSION> D04
(U19)
AT x.xx
HDLA x.xx With HDLA attached only
To Next Page
