Sony HDW-M2000P - Appendix; Analog Betacam Specs and Connector Details

Appendix
A-4 Appendix
Specifications
Analog Betacam playback
Video
Audio
a) Reference level: +4 dBm
Processor adjustment range
Video level ±3 dB/ –∞ to +3 dB selectable
Chroma level ±3 dB/ –∞ to +3 dB selectable
Setup level (59.94i, 29.97PsF mode)
±30 IRE
Black level (50i, 25PsF mode)
±210 mV
Chroma phase ±30°
System phase Sync: ±15 µs
SC: ±200 ns
Input connectors
HDSDI INPUT BNC (1 each for input and for
through output to a monitor)
Serial digital (1.485 Gbits/s)
SMPTE 292M
SDTI INPUT BNC (1) (optional)
SMPTE 305M (SDTI)
Metal tape Oxide tape
Bandwidth Y 30 Hz to 4.5 MHz +0.5 dB/ –4.0 dB 30 Hz to 4.1 MHz +0.5 dB/ –6.0 dB
R–Y/ B–Y 30 Hz to 1.5 MHz +0.5 dB/–3.0 dB 30 Hz to 1.5 MHz +0.5 dB/–3.0 dB
S/N ratio Y
R–Y/ B–Y 48 dB or more 45 dB or more
3% or lessK factor (2T pulse)
3% or less
R–Y/ B–Y
4% or less
Y/C delay
51 dB or more
48 dB or more
LF non-linearity
20 ns or less
2% or less
Y
Metal tape
Oxide tape
Frequency response (at 10 dB
below reference level
a)
)
50 Hz to 15 kHz +1.5 dB/ –3.0 dB 50 Hz to 15 kHz +3.0 dB
S/N ratio (at 3% distortion level) 72 dB or more 50 dB or more (Dolby NR off)
Distortion (THD at 1 kHz reference
level
a)
)
1% or less 2% or less
Wow and flutter 0.1% rms or less
LNG
AFM Frequency response (at reference
level
a)
)
20 Hz to 20 kHz +0.5 dB/–2.0 dB
S/N ratio (at 3% distortion level)
85 dB or more
Distortion (THD at 1 kHz reference
level
a)
)
0.5% or less
REF. VIDEO INPUT
BNC (2 in loop through
connection)
Black burst or composite sync
0.3 Vp-p, 75 Ω, sync negative
AUDIO INPUT CH1/2/3/4
XLR 3-pin, female (4)
LOW OFF: –60 dBu, high
impedance, balanced
HIGH OFF: +4 dBu, high
impedance, balanced
HIGH ON: +4 dBm, 600 Ω
termination, balanced
CUE IN XLR 3-pin, female (1)
LOW OFF: –60 dBu, high
impedance, balanced
HIGH OFF: +4 dBu, high
impedance, balanced
HIGH ON: +4 dBm, 600 Ω
termination, balanced
0.1% rms or less
–
–
–
