Outputs (Analog)
Reproduction frequency range:
28 – 20,000 Hz
Tone
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate Frequency 10.7 MHz
AM tuner section
Tuning range
Models of area code U, CA
With 10-kHz tuning scale: 530 - 1,710 kHz
3)
With 9-kHz tuning scale: 531 - 1,710 kHz
3)
Antenna Loop antenna
Intermediate Frequency 450 kHz
3) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off the
receiver. While holding down PRESET TUNING +
or TUNING +, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
General
Power requirements
Power consumption
Power consumption (during standby mode)
0.3 W
Dimensions (w/h/d) (Approx.)
430 × 145 × 301.5 mm
(17 × 5 6/8 × 11 7/8 inches)
including projecting parts
and controls
Mass (Approx.) 6.5 kg (14 lb 6 oz)
Speaker section
HT-5800DP and HT-4850DP only
Front/surround speakers (SS-MSP68)
Center speaker (SS-CNP68)
Speaker system Full range, magnetically
shielded
Speaker units 80 mm cone type
Enclosure type Bass reflex
Rated Impedance 6 ohms
Dimension (w/h/d) (Approx.)
Front/surround speakers 105 × 170 × 137 mm
(4 1/8 × 6 6/8 × 5 3/8
inches)
Center speaker 265 × 105 × 138 mm
(10 4/8 × 4 1/8 × 5 3/8
inches)
Mass (Approx.)
Front/surround speakers 0.9 kg (1 lb 16 oz)
Center speaker 1.3 kg (2 lb 14 oz)
HT-4800DP only
Front speakers (SS-MSP760L/
SS-MSP760R)
Center speaker (SS-CNP760)
Surround speakers (SS-MSP760SL/
SS-MSP760SR)
Front/center speakers Full range, magnetically
shielded
Surround speakers Full range
Speaker units 80 mm cone type
Enclosure type Bass reflex
Rated Impedance 6 ohms
Dimension (w/h/d) (Approx.)
Front/surround speakers 102 × 150 × 126 mm
(4 × 6 × 5 inches)
Center speaker 225 × 102 × 126 mm
(8 7/8 × 4 × 5 inches)
Mass (Approx.)
Front speakers 0.8 kg (1 lb 13 oz)
Center speaker 1.0 kg (2 lb 4 oz)
Surround speakers 0.7 kg (1 lb 9 oz)
MD/TAPE (OUT),
VIDEO 1 (AUDIO OUT)
Voltage: 800 mV
Impedance: 10 kiloohms
SUB WOOFER Voltage: 2 V
Impedance: 1 kiloohm
Gain levels ±6 dB, 1 dB step
Area code Power requirements
U, CA 120 V AC, 60 Hz
Area code Power consumption
U (STR-K5800P) 180 W
U (STR-K4800P) 165 W
CA 225 VA
continued
