7
GB
Name Function
A ?/1
(on/standby)
Press to turn the receiver
on or off (page 32, 41, 42,
60, 65).
B INPUT
SELECTOR
Turn to select the input
source to play back (page
39, 41, 63, 64).
C Display The current status of the
selected component or a
list of selectable items
appears here (page 8).
D Remote sensor Receives signals from
remote commander.
E MASTER
VOLUME
Turn to adjust the volume
level of all speakers at the
same time (page 38, 39,
41, 42).
F VIDEO 2 IN jacks Connect to a portable
audio/video component
such as a camcorder or
video game (page 30, 36).
G AUTO CAL MIC
jack
Connects to the supplied
optimizer microphone for
the Auto Calibration
function (page 34).
H A.F.D. Press to select a sound
field (page 55).
MOVIE
MUSIC
GAME
MULTI STEREO
MULTI STEREO
lamp
Lights up when multi
stereo sound field is
activated.
I NIGHT MODE Press to enjoy sound
effects for watching movie
at night (page 45, 51, 60).
NIGHT MODE
lamp
Lights up when NIGHT
MODE is activated.
J PHONES jack Connects to headphones
(page 79).
K SUBWOOFER
VOLUME
Turn to adjust the volume
level of the subwoofers.
L ILLUMINATION
The illumination is on
(initial setting).
The illumination is off.
M Illumination
indicator
Lights up to indicate the
subwoofer output level.
Name Function
ON
OFF
