Outputs (Analog)
AUDIO OUT Voltage: 800 mV/
10 kohms
SUBWOOFER Voltage: 2 V/1 kohm
Tone
Gain levels
±6 dB, 1 dB step
Reproduction frequency range:
28 – 20,000 Hz
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Antenna Loop antenna
Intermediate frequency
450 kHz
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B/CB: 0.7 Vp-p, 75 ohms
P
R/CR: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
General
Power requirements
Power output (DIGITAL MEDIA PORT)
DC OUT: 5 V, 0.7 A MAX
System Control output
DC OUT: 5 V, 50mA MAX
Power consumption
• STR-KM7500
• TA-KMSW500
Power consumption (during standby mode)
0.3 W (when
“CTRL:HDMI” in HDMI
menu is set to “CTRL
OFF”)
Dimensions (width/height/depth) including
projecting parts and controls (Approx.)
Receiver 430 × 158 × 342 mm
(17 × 6 1/4 × 13 1/2 in)
Power amplifier 430 × 158 × 332 mm
(17 × 6 1/4 × 13 1/8 in)
Mass (Approx.)
Receiver 8.0 kg (17 lb 11 oz)
Power amplifier 6.6 kg (14 lb 9 oz)
Area code Tuning scale
10 kHz step 9 kHz step
E51, AU, CA 530 –
1,710 kHz
531 –
1,710 kHz
SA 530 –
1,610 kHz
531 –
1,602 kHz
EA – 531 –
1,602 kHz
Area code Power requirements
AU 230 V AC, 50 Hz
SA 230 – 240 V AC, 50/60 Hz
E51 120/220/240 V AC,
50/60 Hz
CA 120 V AC, 60 Hz
EA 120 – 127/220/230 – 240
V AC, 50/60 Hz
Area code Power consumption
AU, E51, CA, SA, EA 220 W
Area code Power consumption
AU, E51, SA, EA 160 W
CA 190 W
