1) Measured under the following conditions:
2) Depending on the sound field settings and the
source, there may be no sound output.
Inputs (Analog)
Inputs (Digital)
Outputs (Analog)
Reproduction frequency range:
28 – 20,000 Hz
Tone
* Models of area code CEL, CEK only.
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate Frequency 10.7 MHz
AM tuner section
Tuning range
Models of area code CA
With 10-kHz tuning scale: 530 - 1,710 kHz
3)
With 9-kHz tuning scale: 531 - 1,710 kHz
3)
Models of area code E51
With 10-kHz tuning scale: 530 - 1,610 kHz
Models of area code CEL, CEK, SP, AU
With 9-kHz tuning scale: 531 - 1,602 kHz
Antenna Loop antenna
Intermediate Frequency 450 kHz
3) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off the
receiver. While holding down PRESET TUNING +
or TUNING +, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
General
Power requirements
Power consumption
Power consumption (during standby mode)
0.3 W
Dimensions (w/h/d) (Approx.)
430 × 145 × 301.5 mm
(17 × 5 6/8 × 11 7/8 inches)
including projecting parts
and controls
Mass (Approx.) 6.5 kg (14 lb 6 oz)
Area code Power requirements
CA 120 V AC, 60 Hz
SP, CEL, CEK 230 V AC, 50 Hz
AU, E51 240 V AC, 50 Hz
MULTI CH IN*, CD,
MD/TAPE, VIDEO 1, 2,
DVD
Sensitivity: 800 mV
Impedance: 50 kiloohms
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
VIDEO 2 (Optical) Sensitivity: –
Impedance: –
MD/TAPE (OUT),
VIDEO 1 (AUDIO OUT)
Voltage: 800 mV
Impedance: 10 kiloohms
SUB WOOFER Voltage: 2 V
Impedance: 1 kiloohms
Gain levels ±6 dB, 1 dB step
Area code Power requirements
CA 120 V AC, 60 Hz
CEL, CEK 230 V AC, 50/60 Hz
AU 240 V AC, 50 Hz
SP 220 – 230 V AC, 50/60 Hz
E51 120/220/240 V AC, 50/60 Hz
Area code Power consumption
CA 225 VA
CEL, CEK, AU, SP 150 W
E51 165 W
