HT-DDW780
2-662-269-11 (1)
Additional Information
Specifications
Amplifier section
Power Output
1)
Models of area code SP
(6 ohms 1 kHz, THD 0.7%)
FRONT
2)
: 70 W/ch
CENTER
2)
: 70 W
SUR
2)
: 70 W/ch
(6 ohms 1 kHz, THD 10%)
FRONT
2)
: 100 W/ch
CENTER
2)
:100 W
SUR
2)
: 100 W/ch
Models of area code CEL, CEK
(6 ohms 1 kHz, THD 0.7%)
FRONT
2)
: 85 W/ch
CENTER
2)
: 85 W
SUR
2)
:85 W/ch
(6 ohms 1 kHz, THD 10%)
FRONT
2)
: 122 W/ch
CENTER
2)
: 122 W
SUR
2)
: 122 W/ch
Models of area code AU
(6 ohms 120 Hz–20 kHz, THD 0.09%)
FRONT
2)
: 50 W/ch
CENTER
2)
: 50 W
SUR
2)
: 50 W/ch
(6 ohms 1 kHz, THD 0.7%)
FRONT
2)
: 85 W/ch
CENTER
2)
: 85 W
SUR
2)
: 85 W/ch
(6 ohms 1 kHz, THD 10%)
FRONT
2)
: 122 W/ch
CENTER
2)
: 122 W
SUR
2)
: 122 W/ch
1)
Measured under the following conditions:
2)
Depending on the sound field settings and the
source, there may be no sound output.
Inputs (Analog)
Inputs (Digital)
Outputs (Analog)
Reproduction frequency range:
28 – 20,000 Hz
Tone
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate Frequency
10.7 MHz
AM tuner section
Tuning range
Models of area code CEL, CEK, SP, AU
With 9-kHz tuning scale:
531 - 1,602 kHz
Antenna Loop antenna
Intermediate Frequency
450 kHz
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B/CB/B-Y: 0.7 Vp-p,
75 ohms
P
R/CR/R-Y: 0.7 Vp-p,
75 ohms
80 MHz HD Pass Through
Area code Power requirements
SP, CEL, CEK 230 V AC, 50 Hz
AU 240 V AC, 50 Hz
SA-CD/CD,
VIDEO 1, 2, DVD
Sensitivity: 800 mV
Impedance: 50 kohms
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
VIDEO 1, 2
(Optical)
Sensitivity: –
Impedance: –
SUB WOOFER Voltage: 2 V
Impedance: 1 kohm
Gain levels ±6 dB, 1 dB step
continued
