6
US
About the indicators on the display
SW
LFE
LCR
SL S SR
;
D
;
PLII
;
PL OPT DTS MEMORY ST
MONOD.RANGECOAX
1 2 3 4 5 6 87
qs qa 9q;
Name Function
A SW Lights up when audio signal is
output from the SUB WOOFER
jack.
B LFE Lights up when the disc being
played back contains an LFE
(Low Frequency Effect)
channel and the LFE channel
signal is actually being
reproduced.
C ; D Lights up when the receiver is
decoding Dolby Digital signals.
Note
When playing a Dolby Digital
format disc, be sure that you
have made digital connections.
D ; PL/
; PLII
“; PL” lights up when the
receiver applies Pro Logic
processing to 2 channel signals
in order to output the center and
surround channel signals.
“; PLII” lights up when the
Pro Logic II Movie/Music
decoder is activated.
E OPT Lights up when VIDEO 2 input
is selected. However,
“UNLOCK” appears on the
display if no digital signal is
input through the OPTICAL
jack.
F DTS Lights up when the receiver is
decoding DTS signals.
Note
When playing a DTS format
disc, be sure that you have made
digital connections.
G MEMORY Lights up when a memory
function, such as Preset
Memory (page 46), etc., is
activated.
Name Function
H Tuner
Indicators
Lights up when using the
receiver to tune in radio stations
(page 44), etc.
I Preset
station
indicators
Lights up when using the
receiver to tune in radio stations
you have preset. For details on
presetting radio stations, see
page 46.
J D.RANGE Lights up when dynamic range
compression is activated (page
32).
K COAX Lights up when DVD input is
selected. However,
“UNLOCK” appears on the
display if no digital signal is
input through the COAXIAL
jack.
L Playback
channel
indicators
L
R
C
SL
SR
S
The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes around
the letters vary to show how the
receiver downmixes the source
sound.
Front Left
Front Right
Center (monaural)
Surround Left
Surround Right
Surround (monaural or the
surround components obtained
by Pro Logic processing)
Example:
Recording format (Front/
Surround): 3/2.1
Sound Field: A.F.D. AUTO
SW
LCR
SL SR
