ICF-703/703L
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JC8 1-216-296-91 SHORT 0
JC9 1-216-296-91 SHORT 0
JC10 1-216-296-91 SHORT 0
JC11 1-216-296-91 SHORT 0 (703L)
JC12 1-216-296-91 SHORT 0 (703L)
< COIL >
L1 1-754-130-11 ANTENNA, FERRITE-ROD (703)
L1 1-754-131-11 ANTENNA, FERRITE-ROD (LW.MW) (703L)
L4 1-406-431-11 COIL (WITH CORE) (OSC)
L5 1-406-028-00 COIL, OSC (MW)
L6 1-428-291-11 COIL, AIR-CORE (EXCEPT 703:IT)
L6 1-428-289-11 COIL, AIR-CORE (703:IT)
L7 1-428-291-11 COIL, AIR-CORE (EXCEPT 703:IT)
L7 1-428-289-11 COIL, AIR-CORE (703:IT)
L8 1-412-959-11 INDUCTOR 47uH
< TRANSISTOR >
Q1 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q2 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q3 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q4 8-729-027-60 TRANSISTOR DTC144TKA-T146 (703)
Q5 8-729-027-60 TRANSISTOR DTC144TKA-T146 (703)
< RESISTOR >
R1 1-216-073-00 METAL CHIP 10K 5% 1/10W
(703L)
R3 1-216-295-91 SHORT 0 (703)
R7 1-216-295-91 SHORT 0 (703)
R10 1-216-049-91 RES-CHIP 1K 5% 1/10W
R12 1-216-049-91 RES-CHIP 1K 5% 1/10W
R13 1-216-049-91 RES-CHIP 1K 5% 1/10W
R14 1-216-097-91 RES-CHIP 100K 5% 1/10W
(703)
< VARIABLE RESISTOR >
RV1 1-225-498-11 RES, VAR, CARBON 50K (VOL)
RV2 1-225-499-11 RES, VAR, CARBON 10K (TONE)
< SWITCH >
S1 1-552-574-21 SWITCH, SLIDE (BAND) (703L)
S2 1-552-370-00 SWITCH, SLIDE (BAND) (703)
< TRANSFORMER >
T1 1-404-790-11 TRANSFORMER, IF
*************************************************************
1-677-381-11 POWER BOARD
*************
< INLET >
0 ACJ1 1-526-838-11 INLET, AC 2P (- AC IN)
< CAPACITOR >
C401 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C402 1-126-927-11 ELECT 2200uF 20.00% 10V
C403 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C404 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C406 1-126-925-11 ELECT 470uF 20.00% 10V
< CONNECTOR >
* CN401 1-568-271-11 SOCKET, CONNECTOR 5P
< DIODE >
D401 8-719-031-85 DIODE 1N4002L
D402 8-719-031-85 DIODE 1N4002L
< JACK >
EPJ1 1-563-836-21 JACK (v)
< JUMPER RESISTOR >
JC402 1-216-296-91 SHORT 0
< COIL >
L401 1-410-294-11 INDUCTOR 38uH (703L)
< RESISTOR >
R401 1-216-017-91 RES-CHIP 47 5% 1/10W
R402 1-216-049-91 RES-CHIP 1K 5% 1/10W
< SWITCH >
S401 1-571-042-11 SWITCH, PUSH (1 KEY) (OPERATION)
*************************************************************
MISCELLANEOUS
***************
ANT1 1-501-222-71 ANTENNA, TELESCOP IC (FM)
SP1 1-529-676-11 SPEAKER (10.2cm)
0 T401 1-435-513-11 TRANSFORMER, POWER
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
0 1-696-562-11 CORD, POWER (EXCEPT UK)
0 1-751-115-11 CORD, POWER (UK)
3-046-205-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, SPANISH, ITALIAN, DUTCH,
SWEDISH, PORTUGUESE, FINNISH, DANISH)
MAIN POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
