Sony ICF-703 - Section 6 Electrical Parts List

– 15 –
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-677-379-11 LED BOARD
**********
< DIODE >
D301 8-719-080-08 LED SLP145B-51 (TUNE)
< RESISTOR >
R301 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R302 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
*************************************************************
* A-3683-164-A MAIN BOARD, COMPLETE (703L)
* A-3683-177-A MAIN BOARD, COMPLETE (703:AEP)
* A-3683-196-A MAIN BOARD, COMPLETE (703:IT)
*********************
3-043-346-01 HOLDER, FERRITE-ROD ANTENNA
3-049-870-01 WOVEN (VOL), FABRIC NON
7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
< FILTER >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-163-102-00 CERAMIC CHIP 24PF 5.00% 50V
(703L)
C2 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
(703L)
C3 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
(EXCEPT 703:IT)
C3 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
(703:IT)
C4 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
(EXCEPT 703:IT)
C4 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
(703:IT)
C6 1-163-255-11 CERAMIC CHIP 150PF 5.00% 50V
(703L)
C7 1-124-261-00 ELECT 10uF 20% 50V
C8 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C9 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C10 1-124-259-11 ELECT 4.7uF 20.00% 16V
C12 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C13 1-124-259-11 ELECT 4.7uF 20.00% 16V
C14 1-124-259-11 ELECT 4.7uF 20.00% 16V
C15 1-124-261-00 ELECT 10uF 20% 50V
C16 1-104-760-11 CERAMIC CHIP 0.047uF 10.00% 50V
C17 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C18 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C19 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
(703L)
C20 1-104-760-11 CERAMIC CHIP 0.047uF 10.00% 50V
C21 1-124-234-00 ELECT 22uF 20% 16V
C22 1-126-925-11 ELECT 470uF 20.00% 10V
C23 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C24 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C25 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C31 1-102-998-11 CERAMIC 5PF 0.50PF 50V
(EXCEPT 703 : IT)
C31 1-102-942-00 CERAMIC CHIP 5PF 0.50PF 50V
(703 : IT)
C37 1-163-088-00 CERAMIC CHIP 5PF 50V
< FILTER >
CF1 1-578-677-11 FILTER, CRYSTAL
CF2 1-577-600-81 FILTER, CERAMIC
CF3 1-577-600-81 FILTER, CERAMIC
CF4 1-577-600-81 FILTER, CERAMIC
< TRIMMER >
CT5 1-141-355-21 CAP, TRIMMER 30PF (703L)
CT6 1-141-320-11 CAP, TRIMMER 45PF (703L)
< VARIABLE CAPACITOR >
CV1 1-151-631-12 CAP, VARIABLE (TUNING)
< DIODE >
D1 8-719-800-76 DIODE 1SS226
< IC >
IC1 8-752-037-02 IC CXA1019S
< JUMPER RESISTOR >
JC1 1-216-296-91 SHORT 0 (703L)
JC2 1-216-296-91 SHORT 0 (703)
JC3 1-216-295-91 SHORT 0
JC4 1-216-296-91 SHORT 0
JC5 1-216-296-91 SHORT 0
JC6 1-216-296-91 SHORT 0
JC7 1-216-296-91 SHORT 0
MAIN
LED
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Abbreviation
IT : Italian model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
