NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
AUS : Australian
When indicating parts by reference num-
ber, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3679-980-A MAIN BOARD ASSY (C113:EXCEPT AUS)
* A-3679-981-A MAIN BOARD ASSY (C113:AUS)
* A-3679-982-A MAIN BOARD ASSY (C113L:AEP)
* A-3679-983-A MAIN BOARD ASSY (C113L:UK)
* A-3679-979-A MAIN BOARD ASSY (C113V)
***************
3-020-880-01 HOLDER (LCD)
* 3-020-884-01 PLATE (LCD), SHIELD
************************************************************
ALARM BOARD
************
< LED >
LD1 8-719-070-81 LED HLMF-K405-2CD (ALARM A RADIO)
LD2 8-719-070-81 LED HLMF-K405-2CD (ALARM B BUZZER)
************************************************************
BACK-LIGHT BOARD
*****************
< JUMPER RESISTOR >
JC14 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113,C113L)
JC15 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113,C113L)
JC30 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113,C113L)
< LED >
LD3 8-719-070-82 LED HLMF-KL05-2CD (LCD BACK-LIGHT)
(C113,C113L)
LD4 8-719-070-82 LED HLMF-KL05-2CD (LCD BACK-LIGHT)
(C113,C113L)
LD5 8-719-070-82 LED HLMF-KL05-2CD (LCD BACK-LIGHT)
(C113,C113L)
LD6 8-719-950-41 LED GL3EG43 (LCD BACK-LIGHT)
LD7 8-719-950-41 LED GL3EG43 (LCD BACK-LIGHT)
LD8 8-719-950-41 LED GL3EG43 (LCD BACK-LIGHT)
LD9 8-719-950-41 LED GL3EG43 (LCD BACK-LIGHT)
< RESISTOR >
R102 1-216-033-00 METAL CHIP 220 5% 1/10W
(C113,C113L)
R103 1-216-033-00 METAL CHIP 220 5% 1/10W
(C113,C113L)
R104 1-216-033-00 METAL CHIP 220 5% 1/10W
(C113,C113L)
R105 1-216-027-00 METAL CHIP 120 5% 1/10W
(C113,C113L)
R105 1-216-029-00 METAL CHIP 150 5% 1/10W
(C113V)
R106 1-216-027-00 METAL CHIP 120 5% 1/10W
(C113,C113L)
R106 1-216-029-00 METAL CHIP 150 5% 1/10W
(C113V)
R107 1-216-027-00 METAL CHIP 120 5% 1/10W
(C113,C113L)
R107 1-216-029-00 METAL CHIP 150 5% 1/10W
(C113V)
R124 1-216-027-00 METAL CHIP 120 5% 1/10W
(C113,C113L)
R124 1-216-029-00 METAL CHIP 150 5% 1/10W
(C113V)
************************************************************
KEY BOARD
**********
< SWITCH >
S51 1-554-303-21 SWITCH, TACTILE (BAND)
S52 1-554-303-21 SWITCH, TACTILE (SNOOZE/DATE/SLEEP OFF)
S53 1-554-303-21 SWITCH, TACTILE (2)
S54 1-554-303-21 SWITCH, TACTILE (TUNE/TIME SET -)
S55 1-554-303-21 SWITCH, TACTILE (5)
S56 1-554-303-21 SWITCH, TACTILE (1)
S57 1-554-303-21 SWITCH, TACTILE (WEATHER)
S58 1-554-303-21 SWITCH, TACTILE (TUNE/TIME SET +)
S59 1-554-303-21 SWITCH, TACTILE (4)
S60 1-554-303-21 SWITCH, TACTILE (CLOCK)
S61 1-554-303-21 SWITCH, TACTILE (RADIO ON, SLEEP)
S62 1-554-303-21 SWITCH, TACTILE (D•S•T• SUMMER T•)
S63 1-554-303-21 SWITCH, TACTILE (3)
S64 1-554-303-21 SWITCH, TACTILE (RADIO OFF, ALARM
RESET)
************************************************************
ALARM
BACK-LIGHT KEY
