SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CABINET (UPPER), FRONT PANEL ASSY REMOVAL
2-2. KEY BOARD, MAIN BOARD, POWER TRANSFOMER REMOVAL
1 Screws (+P 3x35
)
1 Screws (+P 3x35)
2 Screw (+BTP 3x12)
5
5
6
3
4
Front panel assy
Button
Cabinet (Upper)
3 CN1 (2/2)
(2P)
2 CN1 (1/2) (3P)
8 Screw
!º Screws
!¡
!™
!∞
9
6
4
4
6
6
4
4
7
1
Key board
Chassis
Main board
Cabinet (Lower)
Power Transformer
!¢
!£
5
Cord stoper
Holder (Transformer)
Shield case (Transformer
)
Shield plate (P/T)
