C88 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
(C113V)
C89 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C90 1-125-691-11 DOUBLE LAYER 0.022F 0 5.5V
C91 1-163-108-00 CERAMIC CHIP 43PF 5% 50V
C92 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C93 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C94 1-162-638-11 CERAMIC CHIP 1uF 16V
C95 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C96 1-163-059-11 CERAMIC CHIP 0.01uF 10% 50V
C97 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C101 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C102 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C105 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C106 1-104-666-11 ELECT 220uF 20% 25V
C111 1-126-925-11 ELECT 470uF 20% 10V
C112 1-126-926-11 ELECT 1000uF 20% 10V
C113 1-126-926-11 ELECT 1000uF 20% 10V
C116 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C117 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C118 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C120 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C121 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C122 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(C113L)
< FILTER >
* CF1 1-577-319-11 FILTER, CERAMIC (C113,C113V)
CF1 1-578-677-21 FILTER, CRYSTAL (C113L)
CF2 1-579-632-41 FILTER, CERAMIC
CF3 1-579-632-41 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-271-11 SOCKET, CONNECTOR 5P
< TRIMMER >
CT1 1-141-304-21 CAP, TRIMMER 10PF (C113V)
CT3 1-141-304-21 CAP, TRIMMER 10PF
CT4 1-141-443-11 CAP, CERAMIC TRIMMER 30PF (C113L)
CT5 1-141-304-21 CAP, TRIMMER 10PF
CT7 1-141-444-11 CAP, CERAMIC TRIMMER 50PF (C113L)
< DIODE >
D1 8-713-100-11 DIODE 1T362 (C113V)
D2 8-713-100-11 DIODE 1T362 (C113V)
D3 8-719-988-62 DIODE 1SS355 (C113V)
D6 8-719-951-05 DIODE KV1560 (C113,C113V)
D6 8-719-023-99 DIODE KV1563M-3 (C113L)
D7 8-713-100-11 DIODE 1T362 (C113,C113L)
D7 8-719-002-81 DIODE 1T363 (C113V)
D8 8-713-100-11 DIODE 1T362 (C113,C113L)
D8 8-719-002-81 DIODE 1T363 (C113V)
D15 8-719-911-19 DIODE 1SS119 (C113V)
D16 8-719-911-19 DIODE 1SS119 (C113V)
D20 8-719-911-19 DIODE 1SS119
D21 8-719-921-40 DIODE MTZJ-4.7C
D22 8-719-052-88 DIODE 1N4002
D23 8-719-911-19 DIODE 1SS119
D24 8-719-052-88 DIODE 1N4002
D25 8-719-109-88 DIODE RD5.6ES-B1
< IC >
IC1 8-759-204-01 IC TA7358P (C113V)
IC2 8-752-050-16 IC CXA1019M
IC3 8-759-531-36 IC uPD17071GB-523-1A7
< JUMPER RESISTOR >
JC1 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113,C113L:AEP,C113V)
JC2 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113:AUS/C113L:UK,C113V)
JC3 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113:AUS/C113L:AEP)
JC4 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113:EXCEPT AUS/C113L:UK,C113V)
JC5 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113:EXCEPT AUS/C113L:AEP)
JC6 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113L:UK)
JC7 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113V)
JC8 1-216-295-00 METAL CHIP 0 5% 1/10W
JC9 1-216-295-00 METAL CHIP 0 5% 1/10W
JC11 1-216-295-00 METAL CHIP 0 5% 1/10W
JC12 1-216-296-00 METAL CHIP 0 5% 1/8W
JC13 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113V)
JC17 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113,C113V)
JC18 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113)
JC20 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113L)
JC21 1-216-296-00 METAL CHIP 0 5% 1/8W
(C113L)
JC22 1-216-295-00 METAL CHIP 0 5% 1/10W
(C113L)
< COIL >
L1 1-402-969-11 COIL, AIR-CORE (C113V)
L2 1-402-966-11 COIL (OSC) (C113V)
L3 1-402-616-11 ANTENNA, FERRITE-ROD (AM) (C113,C113V)
L3 1-501-715-11 ANTENNA, FERRITE-ROD (LW/MW) (C113L)
L4-1 1-428-290-11 COIL, AIR-CORE
L4-2 1-406-545-11 COIL, AIR-CORE
L5 1-406-545-11 COIL, AIR-CORE
L6 1-406-485-11 COIL (OSC)
L10 1-410-987-11 INDUCTOR CHIP 0.33uH (C113V)
< LIQUID CRYSTAL DISPLAY >
LCD1 1-803-122-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q1 8-729-102-07 TRANSISTOR 2SC2223-F13 (C113V)
Q2 8-729-102-07 TRANSISTOR 2SC2223-F13 (C113V)
Q3 8-729-216-22 TRANSISTOR 2SA1162-G (C113V)
Q4 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (C113V)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
