Sony ICF-C113 - Electrical Parts List - Miscellaneous; Main Board Components; Accessories and Packing Materials

– 24 –
R110 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-097-11 RES,CHIP 100K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
R113 1-216-198-11 RES,CHIP 1K 5% 1/8W
R115 1-216-113-00 METAL CHIP 470K 5% 1/10W
R116 1-216-113-00 METAL CHIP 470K 5% 1/10W
R117 1-216-089-11 RES,CHIP 47K 5% 1/10W
R118 1-216-254-00 RES,CHIP 220K 5% 1/8W
R121 1-216-049-11 RES,CHIP 1K 5% 1/10W
R123 1-216-041-00 METAL CHIP 470 5% 1/10W
< SWITCH >
S1 1-692-181-31 SWITCH, SLIDE (BRIGHTNESS)
< TRANSFORMER >
T1 1-404-674-11 TRANSFORMER, IF (TV MIX) (C113V)
T2 1-404-790-11 TRANSFORMER, IF
< VARIABLE RESISTOR >
VR1 1-225-441-11 RES, VAR, CARBON 50K (VOLUME)
< CONNECTION CORD >
W2 1-782-537-11 CORD, CONNECTION
W5 1-783-719-11 CORD, CONNECTION
W6 1-783-718-11 CORD, CONNECTION
< VIBRATOR >
X50 1-767-517-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
* 1-668-528-11 PRIMARY BOARD (C113,C113V)
* 1-668-528-21 PRIMARY BOARD (C113L)
*************
* 1-535-771-11 TERMINAL (C113,C113L)
************************************************************
* 1-668-529-11 SEDONDARY BOARD (C113,C113V)
* 1-668-529-21 SEDONDARY BOARD (C113L)
***************
< CONNECTION, CORD >
W3 1-783-718-11 CORD, CONNECTION
************************************************************
MISCELLANEOUS
*************
! 14 1-555-795-00 CORD, POWER (C113:EXCEPT AUS/
C113L:AEP) (BLACK,SILVER)
! 14 1-765-458-11 CORD, POWER (C113:AUS)
! 14 1-769-339-22 CORD, POWER (C113V)
! 14 1-769-578-11 CORD, POWER (C113L:UK)
! 14 1-777-921-21 CORD, POWER (C113:EXCEPT AUS/
C113L:AEP) (WHITE)
* 17 1-535-771-11 TERMINAL (C113,C113L)
ANT1 1-501-907-21 ANTENNA, FM WIRE
LCD1 1-803-122-11 DISPLAY PANEL, LIQUID CRYSTAL
SP1 1-504-748-21 SPEAKER (6.6cm)
! T3 1-450-922-11 TRANSFORMER, POWER (C113V)
! T3 1-450-923-11 TRANSFORMER, POWER (C113,C113L)
W2 1-782-537-11 CORD, CONNECTION
W3 1-783-718-11 CORD, CONNECTION
W5 1-783-719-11 CORD, CONNECTION
W6 1-783-718-11 CORD, CONNECTION
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-861-951-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, DUTCH) (C113:AEP,Swiss,
AUS,C113L)
3-861-951-21 MANUAL, INSTRUCTION (ENGLISH) (C113V)
3-861-951-31 MANUAL, INSTRUCTION (SPANISH,
PORTUGUESE,SWEDISH, FINNISH) (C113:AEP)
3-861-951-41 MANUAL, INSTRUCTION (ENGLISH, ITALIAN,
SPANISH, CHINESE) (C113:Italian, E/
C113L:AEP)
3-861-951-51 MANUAL, INSTRUCTION (RUSSIAN, CZECH,
POLISH, HUNGALIAN) (C113:Swiss)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ICF-C113/C113L/C113V
MAIN
PRIMARY SECONDARY
9-925-933-11
Sony Corporation
Personal & Mobile Communication Company
98C0284-1
Printed in Japan © 1998.3
Published by Quality Assurance Dept.
