Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-671-841-11 ALARM KEY BOARD
****************
< SWITCH >
S201 1-553-856-00 SWITCH, KEYBOARD (–, ALARM TIME)
S202 1-553-856-00 SWITCH, KEYBOARD (+, ALARM TIME)
S203 1-553-856-00 SWITCH, KEYBOARD (B, ON/OFF)
S204 1-553-856-00 SWITCH, KEYBOARD (–, ALARM TIME)
S205 1-553-856-00 SWITCH, KEYBOARD (+, ALARM TIME)
S206 1-553-856-00 SWITCH, KEYBOARD (A, ON/OFF)
*************************************************************
A-3663-208-A MAIN BOARD, COMPLETE (C793: US, CND)
A-3663-266-A MAIN BOARD, COMPLETE (C793: AUS)
A-3663-268-A MAIN BOARD, COMPLETE (C793: AEP, SP)
A-3663-272-A MAIN BOARD, COMPLETE (C793L: FR)
A-3663-275-A MAIN BOARD, COMPLETE (C793L: UK)
*********************
3-032-464-01 HOLDER (LCD)
< ANTENNA >
ANT1 1-501-907-21 ANTENNA, FM WIRE (FM LEAD ANTENNA)
< BAND PASS FILTER >
BPF1 1-236-711-21 FILTER, BAND PASS
< CAPACITOR >
C1 1-163-253-11 CERAMIC CHIP 120PF 5% 50V
(C793L)
C6 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C7 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C8 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C9 1-163-224-11 CERAMIC CHIP 7PF 0.25PF 50V
C11 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C12 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(C793L)
C15 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C793: US, CND)
C16 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C793: US, CND)
C17 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C793: US, CND)
C20 1-163-059-91 CERAMIC CHIP 0.01uF 10% 50V
C21 1-126-963-11 ELECT 4.7uF 20% 50V
C22 1-126-964-11 ELECT 10uF 20% 50V
C23 1-163-063-00 CERAMIC CHIP 0.022uF 10% 50V
C24 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C25 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
(C793L)
C26 1-126-964-11 ELECT 10uF 20% 50V
C27 1-163-085-00 CERAMIC CHIP 2PF 50V
C28 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C29 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
(C793)
C29 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(C793L)
C30 1-126-960-11 ELECT 1uF 20% 50V
C31 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C32 1-163-132-00 CERAMIC CHIP 430PF 5% 50V
C33 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C34 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
(C793L)
C41 1-126-934-11 ELECT 220uF 20% 10V
C42 1-128-551-11 ELECT 22uF 20% 25V
C43 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C44 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C45 1-126-934-11 ELECT 220uF 20% 10V
C46 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
(C793L)
C47 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C48 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C50 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C51 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C53 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C54 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C55 1-126-935-11 ELECT 470uF 20% 6.3V
C56 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(C793L)
C57 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C59 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C60 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C62 1-126-934-11 ELECT 220uF 20% 10V
C63 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C66 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C100 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C101 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
AUS : Australian model
CND : Canadian model
FR : French model
SP : Singapore model
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
-11 : Suffix-11
-12 : Suffix-12
ALARM KEY MAIN
