TC2 L1-2 L1 (L1-1 * )
AM (MW) Tracking Adjustment
LW Tracking Adjustment
*
L3 TC3
FM Tracking Adjustment
T1 AM IF
TC1 AM (MW) Tracking Adjustment
L4 FM VCO Voltage Adjustment
L5 AM (MW) VCO Voltage Adjustment
TC4 LW VCO Voltage Adjustment *
TP (VT)
TP (SP+)
TP (SP GND)
TP (FM-IN)
– MAIN BOARD (Component Side) – – MAIN BOARD (Conductor Side) –
Adjustment Location:
*) ICF-C793L
