CABINET (UPPER)
CABINET (FRONT) SUB ASSY
2 two claws
1 screw (2 × 8)
2 three claws
3 cabinet (upper)
2 four claws
1 screw (2 × 8)
6 cabinet (front) sub assy
5 cover
knob (open)
2 Slide the knob (open)
in the direction of the
arrow A , and open th
e
cabinet front assy.
cabinet (front) assy
1 screw (2 × 8)
3 connector (CN701)
4 Pull out two flat wires.
