Sony ICF-CD543RM - Page 44

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
44
ICF-CD543RM
S417 1-786-050-21 SWITCH, KEY BOARD (RADIO ON/BAND)
< VIBRATOR >
X401 1-579-901-11 VIBRATOR, CERAMIC (4.19MHz)
X402 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
* 1-671-072-11 LOADING BOARD
**************
< CAPACITOR >
C651 1-126-947-11 ELECT 47uF 20% 10V
C653 1-127-888-21 CERAMIC 0.1uF 10% 50V
C654 1-127-888-21 CERAMIC 0.1uF 10% 50V
C656 1-127-888-21 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
* CN651 1-785-672-11 PIN, CONNECTOR (PC BOARD) 6P
< IC >
IC651 8-759-962-08 IC BA6208
< SWITCH >
S651 1-771-489-11 SWITCH, LEVER SLIDE
(TRAY OPEN/CLOSE DETE CT)
**************************************************************
* A-3021-773-A MAIN BOARD, COMPLETE (US)
* A-3021-881-A MAIN BOARD, COMPLETE (CND)
* A-3323-863-A MAIN BOARD, COMPLETE (AEP)
*********************
7-685-146-14 SCREW +P 3X8 TYPE2 NON-SLIT
< BAND-PASS FILTER >
BPF1 1-239-813-21 FILTER, BAND PASS (US)
BPF1 1-236-711-21 FILTER, BAND PASS (CND, AEP)
< CAPACITOR >
C1 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C2 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C4 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C6 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C9 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C11 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
(US)
C12 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(US)
C12 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(CND, AEP)
C13 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C14 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C15 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C16 1-126-963-11 ELECT 4.7uF 20% 50V
C17 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C18 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C19 1-104-665-11 ELECT 100uF 20% 10V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C22 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C23 1-128-551-11 ELECT 22uF 20% 25V
C24 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C25 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C26 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C27 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C28 1-126-963-11 ELECT 4.7uF 20% 50V
C29 1-126-964-11 ELECT 10uF 20% 50V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C31 1-104-665-11 ELECT 100uF 20% 10V
C32 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C33 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C34 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C36 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C37 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C38 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C39 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C40 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C43 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(US)
C51 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C52 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C53 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C54 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C55 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C56 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C57 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C58 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C59 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C60 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C61 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C62 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C63 1-128-551-11 ELECT 22uF 20% 25V
C64 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C65 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C66 1-126-947-11 ELECT 47uF 20% 35V
C67 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C68 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C69 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C70 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C71 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(US)
C101 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C102 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C103 1-126-964-11 ELECT 10uF 20% 50V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C113 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C116 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C117 1-126-963-11 ELECT 4.7uF 20% 50V
C131 1-126-963-11 ELECT 4.7uF 20% 50V
C151 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C171 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C172 1-126-963-11 ELECT 4.7uF 20% 50V
C173 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
LCD LOADING MAIN
