Sony ICF-CD543RM - Panel (Front) Section; Holder (MD)

ICF-CD543RM
7
3-4. PANEL (FRONT) SECTION
3-5. HOLDER (MD)
2 two screws
(P2.6
× 8)
1 parallel wire lead
(CN301)
3
7 screw
(BTP3
× 14)
8 two screws
(P2.6
× 8)
9 claw
0 panel (front) section
9 claw
8 two screws
(P2.6
× 8)
7 screw
(BTP3
× 14)
6 parallel wire lead
(CN1)
5 relay board
4 two parallel wire leads
(CN671, CN672)
2 holder (MD
)
1 two screws
(BTP3 × 14)
1 two screws
(BTP3 × 14)
