– 34 –
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
JACK KEY MAIN
* 1-668-919-11 JACK BOARD (TYPE A)
* 1-668-919-12 JACK BOARD (TYPE B)
(EXCEPT CD820: US, Canadian)
***********
< JACK >
J301 1-566-891-11 JACK (2)
< CABLE HOLDER >
* KH303 1-568-135-21 HOLDER, CABLE 7P
< COIL >
L101 1-410-526-11 INDUCTOR 10uH
L201 1-410-526-11 INDUCTOR 10uH
L303 1-410-324-11 INDUCTOR 4.7uH
************************************************************
* 1-668-915-11 KEY BOARD (TYPE A)
* 1-668-915-12 KEY BOARD (TYPE B)
**********
1-775-826-11 CORD, CONNECTION
< SWITCH >
S401 1-554-937-11 SWITCH, KEY BOARD (WAKE UP/TRACK)
S402 1-554-937-11 SWITCH, KEY BOARD (ALARM MODE)
S403 1-554-937-11 SWITCH, KEY BOARD (ALARM B)
S404 1-554-937-11 SWITCH, KEY BOARD (RADOI/SLEEP)
S405 1-554-937-11 SWITCH, KEY BOARD (+ +)
S406 1-554-937-11 SWITCH, KEY BOARD (ALARM A)
S407 1-554-937-11 SWITCH, KEY BOARD (CD ^)
S408 1-554-937-11 SWITCH, KEY BOARD (= -)
S409 1-554-937-11 SWITCH, KEY BOARD (TRACK/CLOCK)
S410 1-554-937-11 SWITCH, KEY BOARD (OFF/ALARM RESET)
S411 1-554-937-11 SWITCH, KEY BOARD (SNOOZE/SLEEP OFF)
************************************************************
* A-3679-973-A MAIN BOARD, COMPLETE (CD820: US)
* A-3679-984-A MAIN BOARD, COMPLETE (CD820: AEP, SP)
* A-3679-988-A MAIN BOARD, COMPLETE (CD820: IT)
* A-3679-989-A MAIN BOARD, COMPLETE (CD820L: FR)
* A-3679-990-A MAIN BOARD, COMPLETE (CD820L: AEP)
* A-3679-991-A MAIN BOARD, COMPLETE (CD820L: UK)
* A-3683-000-A MAIN BOARD, COMPLETE (CD820: Canadian)
* A-3683-010-A MAIN BOARD, COMPLETE (CD820: AUS)
**********************
* 3-026-566-01 SPACER (C)
3-928-285-01 KNOB (VOL)
< ANTENNA >
ANT1 1-501-907-21 ANTENNA, FM WIRE
< CAPACITOR >
C1 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C2 1-163-086-00 CERAMIC CHIP 3PF 50V
(CD820/CD820L: AEP, UK)
C2 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
(CD820L: FR)
C3 1-163-100-00 CERAMIC CHIP 20PF 5% 50V
(EXCEPT CD820: IT/CD820L)
C3 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
(CD820: IT)
C4 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
(EXCEPT CD820: IT/CD820L)
C4 1-163-104-00 CERAMIC CHIP 30PF 5% 50V
(CD820: IT)
C5 1-163-086-00 CERAMIC CHIP 3PF 50V
(CD820/CD820L: AEP)
C5 1-163-083-00 CERAMIC CHIP 1PF 50V
(CD820L: UK)
C5 1-163-122-00 CERAMIC CHIP 160PF 5% 50V
(CD820L: FR)
C6 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
(CD820L: AEP, UK)
C7 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(CD820: US/CD820L: UK)
C7 1-164-232-11 CERAMIC CHIP 0.01uF 50V
(CD820L: AEP)
• Abbreviation
AUS : Australian
FR : French
IT : Italian
SP : Singapore
TYPE A
TYPE B
