– 39 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R528 1-216-113-00 METAL CHIP 470K 5% 1/10W
R529 1-216-097-00 RES, CHIP 100K 5% 1/10W
R530 1-216-113-00 METAL CHIP 470K 5% 1/10W
R531 1-216-095-00 METAL CHIP 82K 5% 1/10W
R533 1-216-097-00 RES, CHIP 100K 5% 1/10W
R534 1-216-089-00 RES, CHIP 47K 5% 1/10W
R535 1-216-073-00 RES, CHIP 10K 5% 1/10W
R536 1-216-093-00 METAL CHIP 68K 5% 1/10W
R537 1-216-101-00 METAL CHIP 150K 5% 1/10W
R540 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R541 1-216-049-11 RES, CHIP 1K 5% 1/10W
R542 1-216-073-00 RES, CHIP 10K 5% 1/10W
R543 1-216-121-00 RES, CHIP 1M 5% 1/10W
R544 1-216-073-00 RES, CHIP 10K 5% 1/10W
R545 1-216-105-00 RES, CHIP 220K 5% 1/10W
R546 1-216-073-00 RES, CHIP 10K 5% 1/10W
R547 1-216-097-00 RES, CHIP 100K 5% 1/10W
R548 1-216-073-00 RES, CHIP 10K 5% 1/10W
R549 1-216-073-00 RES, CHIP 10K 5% 1/10W
R550 1-216-097-00 RES, CHIP 100K 5% 1/10W
R551 1-216-049-11 RES, CHIP 1K 5% 1/10W
R552 1-216-049-11 RES, CHIP 1K 5% 1/10W
R553 1-216-049-11 RES, CHIP 1K 5% 1/10W
R554 1-216-049-11 RES, CHIP 1K 5% 1/10W
R555 1-216-049-11 RES, CHIP 1K 5% 1/10W
R556 1-216-049-11 RES, CHIP 1K 5% 1/10W
R557 1-216-049-11 RES, CHIP 1K 5% 1/10W
R558 1-216-049-11 RES, CHIP 1K 5% 1/10W
R559 1-216-049-11 RES, CHIP 1K 5% 1/10W
R560 1-216-049-11 RES, CHIP 1K 5% 1/10W
R561 1-216-073-00 RES, CHIP 10K 5% 1/10W
R570 1-216-073-00 RES, CHIP 10K 5% 1/10W
R571 1-216-081-00 METAL CHIP 22K 5% 1/10W
R572 1-216-081-00 METAL CHIP 22K 5% 1/10W
R573 1-216-089-00 RES, CHIP 47K 5% 1/10W
R574 1-216-089-00 RES, CHIP 47K 5% 1/10W
R575 1-216-073-00 RES, CHIP 10K 5% 1/10W
R576 1-216-049-11 RES, CHIP 1K 5% 1/10W
R577 1-216-113-00 METAL CHIP 470K 5% 1/10W
R901 1-216-097-00 RES, CHIP 100K 5% 1/10W
! R902 1-219-149-11 FUSIBLE 1 5% 1/4W F
(EXCEPT CD820: US)
! R903 1-219-149-11 FUSIBLE 1 5% 1/4W F
(EXCEPT CD820: US)
R905 1-216-049-11 RES, CHIP 1K 5% 1/10W
R906 1-216-033-00 METAL CHIP 220 5% 1/10W
R907 1-216-033-00 METAL CHIP 220 5% 1/10W
R908 1-216-089-00 RES, CHIP 47K 5% 1/10W
R909 1-216-049-11 RES, CHIP 1K 5% 1/10W
R910 1-216-033-00 METAL CHIP 220 5% 1/10W
R911 1-216-049-11 RES, CHIP 1K 5% 1/10W
R912 1-216-089-00 RES, CHIP 47K 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-241-765-11 RES, ADJ, CARBON 22K
RV301 1-223-966-11 RES, VAR, CARBON 50K (VOLUME)
RV501 1-230-497-11 RES, ADJ, CARBON 22K
RV502 1-230-497-11 RES, ADJ, CARBON 22K
< SWITCH >
S1 1-692-181-21 SWITCH, SLIDE (BAND) (CD820/CD820L: FR)
S1 1-572-633-11 SWITCH, SLIDE (BAND) (CD820L: AEP, UK)
< TRANSFORMER >
T1 1-404-790-11 TRANSFORMER, IF (CD820)
T1 1-404-902-11 TRANSFORMER, IF (CD820L: AEP, UK)
T1 1-404-902-21 TRANSFORMER, IF (CD820L: FR)
< VIBRATOR >
X401 1-760-641-21 VIBRATOR, CERAMIC (4.19MHz)
X402 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
X501 1-760-793-11 VIBRATOR, CERAMIC (16.933MHz)
************************************************************
* 1-668-918-11 MOTOR BOARD (TYPE A)
* 1-668-918-12 MOTOR BOARD (TYPE B)
*************
< SWITCH >
S570 1-571-936-11 SWITCH, LEAF (LIMIT)
************************************************************
* 1-668-917-11 POWER BOARD (TYPE A)
* 1-668-917-12 POWER BOARD (TYPE B)
*************
! 1-769-339-22 CORD, POWER (CD820: US, Canadian)
! 1-555-795-00 CORD, POWER
(CD820: AEP, IT, SP/CD820L: AEP, FR)
! 1-765-458-11 CORD, POWER (CD820: AUS)
! 1-555-795-00 CORD, POWER
(CD820: IT, SP/CD820L: AEP, FR)
! 1-696-572-21 CORD, POWER (CD820L: UK)
! 1-769-578-11 CORD, POWER (CD820L: UK)
< CABLE HOLDER >
* KH901 1-573-287-11 HOLDER, CABLE 2P
< LINE FILTER >
! L901 1-424-150-11 TRANSFORMER, LINE FILTER
< TRANSFORMER >
! T901 1-423-904-21 TRANSFORMER, POWER
(CD820: US, Canadian)
! T901 1-423-905-21 TRANSFORMER, POWER
(EXCEPT CD820: US, Canadian)
< TERMINAL >
* TM1 1-535-771-11 TERMINAL (EXCEPT CD820: US, Canadian)
* TM2 1-535-771-11 TERMINAL (EXCEPT CD820: US, Canadian)
************************************************************
MAIN MOTOR POWER
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
