– 40 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 1-668-916-11 SWITCH BOARD (TYPE A)
* 1-668-916-12 SWITCH BOARD (TYPE B)
*************
< SWITCH >
S420 1-692-080-11 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
************************************************************
MISCELLANEOUS
***************
4 1-452-732-11 MAGNET
12 1-775-826-11 CORD, CONNECTION
! 53 1-555-795-00 CORD, POWER
(CD820: AEP, IT, SP/CD820L: AEP, FR)
! 53 1-696-572-21 CORD, POWER (CD820L: UK)
! 53 1-765-458-11 CORD, POWER (CD820: AUS)
! 53 1-769-339-22 CORD, POWER (CD820: US, Canadian)
55 1-769-824-11 WIRE (FLAT TYPE) (16 CORE)
! 101 8-848-379-31 OPTICAL PICK-UP KSS-213B
M571 X-2625-769-1 GEAR ASSY (MB), MOTOR (SLED)
M572 X-2625-770-2 CHASSIS ASSY (MB), (RP) (SPINDLE)
SP101 1-504-460-11 SPEAKER (7.7CM) (L-CH)
SP201 1-504-460-11 SPEAKER (7.7CM) (R-CH)
! T901 1-423-904-21 TRANSFORMER, POWER
(CD820: US, Canadian)
! T901 1-423-905-21 TRANSFORMER, POWER
(EXCEPT CD820: US, Canadian)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-649-79 SCREW +P 3X14 TYPE2 NON-SLIT
#2 7-685-133-19 SCREW +BTP 2.6X6 TYPE2 N-S
#3 7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
#4 7-621-255-15 SCREW +P 2X3
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
* 3-704-286-01 BAG (STANDARD), PROTECTION
3-862-235-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, GERMAN, DUTCH)
(CD820: AEP, IT, SP, AUS/CD820L)
3-862-235-21 MANUAL, INSTRUCTION
(ENGLISH, FRENCH) (CD820: US, Canadian)
3-862-235-31 MANUAL, INSTRUCTION
(SPANISH, SWEDISH, ITALIAN, PORTUGUESE)
(CD820: AEP, IT/CD820L: FR)
ICF-CD820/CD820L
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Sony Corporation
Personal A&V Products Company
9-923-394-11
98D0590-1
Printed in Japan © 1998. 4
Published by Quarity Engineering Dept.
(Shibaura)
