Sony ICF-CD832 - Page 37

37
ICF-CD832
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R421 1-216-841-11 METAL CHIP 47K 5% 1/10W
R423 1-216-841-11 METAL CHIP 47K 5% 1/10W
R425 1-216-841-11 METAL CHIP 47K 5% 1/10W
R426 1-216-833-11 METAL CHIP 10K 5% 1/10W
R427 1-216-821-11 METAL CHIP 1K 5% 1/10W
R428 1-216-821-11 METAL CHIP 1K 5% 1/10W
R429 1-216-821-11 METAL CHIP 1K 5% 1/10W
R430 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R432 1-216-809-11 METAL CHIP 100 5% 1/10W
R433 1-216-809-11 METAL CHIP 100 5% 1/10W
R434 1-216-809-11 METAL CHIP 100 5% 1/10W
R435 1-216-821-11 METAL CHIP 1K 5% 1/10W
R436 1-216-833-11 METAL CHIP 10K 5% 1/10W
R437 1-216-821-11 METAL CHIP 1K 5% 1/10W
R438 1-216-821-11 METAL CHIP 1K 5% 1/10W
R439 1-216-821-11 METAL CHIP 1K 5% 1/10W
R441 1-216-833-11 METAL CHIP 10K 5% 1/10W
R443 1-216-837-11 METAL CHIP 22K 5% 1/10W
R444 1-216-845-11 METAL CHIP 100K 5% 1/10W
R445 1-216-821-11 METAL CHIP 1K 5% 1/10W
R446 1-216-821-11 METAL CHIP 1K 5% 1/10W
R447 1-216-821-11 METAL CHIP 1K 5% 1/10W
R448 1-216-821-11 METAL CHIP 1K 5% 1/10W
R449 1-216-821-11 METAL CHIP 1K 5% 1/10W
R450 1-216-821-11 METAL CHIP 1K 5% 1/10W
R451 1-216-821-11 METAL CHIP 1K 5% 1/10W
R452 1-216-821-11 METAL CHIP 1K 5% 1/10W
R457 1-216-833-11 METAL CHIP 10K 5% 1/10W
R458 1-216-821-11 METAL CHIP 1K 5% 1/10W
R459 1-216-813-11 METAL CHIP 220 5% 1/10W
R460 1-216-853-11 METAL CHIP 470K 5% 1/10W
R461 1-216-821-11 METAL CHIP 1K 5% 1/10W
R463 1-249-401-11 CARBON 47 5% 1/4W
R464 1-216-833-11 METAL CHIP 10K 5% 1/10W
R465 1-216-821-11 METAL CHIP 1K 5% 1/10W
R466 1-216-841-11 METAL CHIP 47K 5% 1/10W
R467 1-216-833-11 METAL CHIP 10K 5% 1/10W
R468 1-216-833-11 METAL CHIP 10K 5% 1/10W
R469 1-216-837-11 METAL CHIP 22K 5% 1/10W
R470 1-216-821-11 METAL CHIP 1K 5% 1/10W
R471 1-216-821-11 METAL CHIP 1K 5% 1/10W
R472 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R551 1-216-813-11 METAL CHIP 220 5% 1/10W
R552 1-216-841-11 METAL CHIP 47K 5% 1/10W
R903 1-216-833-11 METAL CHIP 10K 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/10W
R905 1-249-401-11 CARBON 47 5% 1/4W
R906 1-216-809-11 METAL CHIP 100 5% 1/10W
R907 1-247-807-31 CARBON 100 5% 1/4W
R908 1-216-813-11 METAL CHIP 220 5% 1/10W
R909 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R911 1-216-841-11 METAL CHIP 47K 5% 1/10W
R912 1-216-845-11 METAL CHIP 100K 5% 1/10W
< VARIABLE RESISTOR >
RV301 1-225-764-12 RES, VAR, CARBON 20KX2 (VOLUME)
< SWITCH >
S1 1-692-181-21 SWITCH, SLIDE (BAND)
< COIL >
T1 1-424-703-11 COIL (AM IFT)
T2 1-424-702-11 COIL (FM DET)
< VIBRATOR >
X401 1-760-252-12 VIBRATOR, CRYSTAL (32kHz)
X402 1-579-901-11 VIBRATOR, CERAMIC (4.19MHz)
*************************************************************
* A-3347-585-A TRANSFORMER BOARD, COMPLETE
******************************
< CAPACITOR >
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C905 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C907 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
< CABLE HOLDER >
* CH901 1-565-386-11 HOLDER, CABLE 5P
< DIODE >
D901 8-719-911-19 DIODE 1SS119-25
D902 8-719-911-19 DIODE 1SS119-25
D903 8-719-031-85 DIODE 1N4002L
D904 8-719-031-85 DIODE 1N4002L
D905 8-719-031-85 DIODE 1N4002L
D906 8-719-031-85 DIODE 1N4002L
< COIL >
L901 1-410-513-11 INDUCTOR 22uH
L902 1-410-513-11 INDUCTOR 22uH
< RESISTOR >
R901 1-216-845-11 METAL CHIP 100K 5% 1/10W
R902 1-216-841-11 METAL CHIP 47K 5% 1/10W
*************************************************************
MAIN TRANSFORMER
