Part Names and Functions
IFU-WLM1
4-103-420-12 (1)
C:\data\Projector\LanModule\2635317112\2635317112_IFUWLM2\GB
03INTRO.fm
masterpage:Left
Part Names and Functions
a WIRELESS LAN/MEMORY indicators
Either indicator lights to show the current selection of the WIRELESS LAN/
MEMORY switch.
b WIRELESS LAN/MEMORY switch
Slide the switch to either of the following positions, depending on the desired
operation.
WIRELESS LAN: Use it as a wireless LAN module.
MEMORY: Use it as a flash memory device.
c USB connector
Used to connect the unit to the device that you want to use for communication.
d Cap
Protects the USB connector when the USB Wireless LAN Module is not
connected to another device.
4
3
2
1
