Identifying parts
GB
16
L Tripod socket hole
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage
to the camera may occur.
* For details on compatible accessories
for the Multi/Micro USB Terminal,
visit the Sony website, or consult your
Sony dealer or local authorized Sony
service facility.
DT 18-55mm F3.5-5.6 SAM II
(Supplied with the ILCA-68K)
A Focusing ring
B Zoom ring
C Focal-length scale
D Focal-length index
E Lens contacts*
F Focusing mode switch
G Mounting index
* Do not directly touch this part.
• The DT 18-55mm F3.5-5.6 SAM
II is designed for Sony A-mount
cameras (models equipped with
an APS-C sized image sensor).
You cannot use these lenses on
35mm-format cameras.
• For the lenses other than DT 18-
55mm F3.5-5.6 SAM II, refer to
the operating instructions
supplied with the lens.
Lens
