Identifying parts
GB
20
A Image sensor position
mark
B Speaker
C m (Microphone) jack
• When an external microphone
is connected, the microphone is
turned on automatically. If the
external microphone is a plug-
in-power type, the power of the
microphone is supplied by the
camera.
D i (Headphones) jack
E Multi/Micro USB Terminal*
• Supports Micro USB
compatible device.
F Charge lamp (49)
G HDMI micro jack
H Multi interface shoe*
• Some of the accessories may
not be inserted fully and
protrude backward from the
Multi interface shoe. However,
when the accessory reaches the
front end of the shoe, the
connection is completed.
I Mode dial (69)
J C2 (Custom 2) button (28)
K C1 (Custom 1) button (28)
L Exposure compensation dial
(28)
Top side/Side view
