3.7.1 HDMI – No picture – General Checking (Continued)
END
[OK] Picture recovered
Check impedance of series
resistor at SCL&SDA during AC OFF
HDMI1: R4004 & R4007 (I2C)
HDMI2: R4005 & R4008 (I2C)
HDMI3: R4003 & R4006 (I2C)
Continue..
Series Resistor Broken.
Replace → Re-verify
[NG] Impedance ≠
100
Ω±5%
[NG] No picture
[OK] Impedance ≈ 100
Ω±5%
Check voltage of SCL&SDA line
HDMI1: CN4001 – Pin 15 & 16
HDMI2: CN4002 – Pin 15 & 16
HDMI3: CN4000 – Pin 15 & 16
Go to
“I2C Failure Analysis“
Page
[NG] VI2C ≠ 3.5 ~ 5.5V
[OK] VI2C = 3.5 ~ 5.5V
Check voltage of TMDS line
HDMI1: CN4001 – Pin1,3,4,6,7,9,10,12
HDMI2: CN4002 – Pin1,3,4,6,7,9,10,12
HDMI3: CN4000 – Pin1,3,4,6,7,
9,10,12
[NG] VTMDS ≠ 2.6 ~ 3.5V
Go to
“TMDS Failure Analysis“
Page
[OK] VTMDS = 2.6 ~ 3.5V
Replace B-board &
re-verify
Escalate this issue to
R&D team
END
Checking condition:
- TV ON & HDMI Source ON except if the flow mentioned is AC OFF.
- TV HDMI input connected to HDMI source (Player etc.)
- TV Input Selection: HDMI
