KLV-32/40/46/52W400A (GA) 1-4
KLV-32W400A
1-1-4. BG1G BOARD REMOVAL
3 One screw
(+BVST 3X8)
5 Five screws
(+BVST 3X8)
9 Two screws
(+BVST 3X8)
5 Four screws
(+BVST 3X8)
8 BG1G board
4 B (J) shield
q; Main bracket assy
7 Harness with connector
(LVDS)
6 One screw
(+BVST 3X8)
2 Two screws
(SP 4-4O UNC)
1 Four screws
(+PSW M3x5)
