KLV-32/40/46/52W400A (GA) 1-25
KLV-52W400A
1-4-3. D4, D5, G5 AND BG1B BOARDS REMOVAL
1 Two screws
(+PSW M5X8)
ql D4 board
qj G5 board
8 One screw
(+BVST 3X8)
3 Four screws
(+BVST 3X8)
5 Two screws
(+BVST 3X8)
4 D5 board
5 D5 frame
7 Side jack bracket assy
2 Center frame
9 Harness with
connector (LVDS)
qg Main bracket
assy
qf Two screws
(+BVST 3X8)
qk Four SCREWS
(+BVST 3X8)
qd BG1G board
qs Three screws
(+BVST 3X8)
qs Six screws
(+BVST 3X8)
0 Two screws
(+BVST 3X8)
qf Three screws
(+BVST 3X8)
qh Three screws
(+BVST 3X8)
qa B(G) shield
