– 2 –
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
B/G/H E2..12 21..69 C02 C03 C04..C12 C21..C69
CABLE TV (1) S1..41 S01 S02..S41
CABLE TV (2) S01..S05 M1..M10 U1..U10 S42..S46 S01..S10 S11..S20
ITALY A B C D E F G H H1 H2 21..69 C11..C69
D/K R01..R12 R21..R69 C02..C12 C21..C69
CABLE TV (1) S01 S02..S41
CABLE TV (2) S42 S43..S46
CABLE TV B.. O S21..41 S02.S03..S17.
S21..S41
L F2..F10 F21 F69 C01..C12 C21..C69
I B21..B68 C21..C68
Iudication on the screen
Receivable channel
Receivable Channel and Channel Displays
Television system B/G/H,D/K,I,L
Colour system PAL/SECAM
NTSC 3.58/NTSC4.43(VIDEO IN)
Channel coverage See " Receivable channels and channel
displays " on this page.
Projected picture size 41 inches
Approx. 103cm measured diagonally
Terminals
Rear Center speaker input terminals, 2 terminals
(L, R), audio outputs-phono jack
W 1 21-pin Euro connector
(CENELEC standard)
- inputs for audio and video signals
- inputs for RGB
- outputs of TV audio and video signals
: 2/ q 2 21-pin EURO connector
- inputs for audio and video signals
- inputs for S Video
- outputs for audio and video signals
(selectable)
: 3/ q 3 21-pin Euro connector
- inputs for audio and video signals
- inputs for S video
- outputs for audio and video signals
(selectable, the same output source as the
: 2/ q 2 connector)
SPECIFICATIONS
Front q 3 S video input-4-pin DIN
… 3 video inputs-phono jack
– (L.R), Audio inputs-phono jacks
"2 Headphone jack -stereo minijack
Sound output 2 x 30W (music power)
2 x 15W (RMS)
Centre SP input 30W (RMS)(using as the centre speaker)
Power consumption 155W
Dimensions(WxHxD) 948x992x 511 mm
(37
3
/
8
x 39
1
/
8
x 20
1
/
8
inches)
Mass Approx. 43kg (94 lbs 13 oz)
Supplied accessories See page 6.
Other features Digital comb filter (High resolution)
FASTEXT
Design and specifications are subject to change without notice.
