Sony M-450 - 2 Disassembly; Cassette Holder Asssy; Cabinet (Rear)

4
M-450/455
SECTION 2
DISASSEMBLY
2-1. CASSETTE HOLDER ASSY
2-2. CABINET (REAR)
z
CAUTIONS DURING ASSEMBLY
Align these switches and knobs
S601 t Knob (pause)
Lever (F/R) t Knob (FR)
Cassette holder ASSY Set Cabinet (rear) Cabinet (front) Main board, Mechanism deck Head, magnetic (HRPE901)
Motor (M901)
r
The equipment can be removed using the following procedure.
Cassette holder ASS
Y
2
3
1 Eject
4 Claws
Cabinet (front)
4
1
Lever (F/R)
Lid, battery case
Knob (FR)
Knob (pause)
Cabinet (rear)
S601
2 Screw
(B1.7
× 5)
3 Four screws
(1.7
× 16)
5 Claw
6
