Sony MHC-DP700 - Except for North American and European Models

31
Additional Information
Inputs
GAME IN: voltage 250 mV,
(phono jacks) impedance 47 kilohms
MD/VIDEO IN: voltage 450 mV/250 mV,
(phono jacks) impedance 47 kilohms
OPTICAL IN:
(Square optical connector jacks, front panel (North
American and European models only), or front and
rear panels (except for North American and European
models))
wavelength ——
MIC: sensitivity 1 mV,
(Except for North impedance 10 kilohms
American and
European models)
(phone jack)
Outputs
MD (VIDEO) OUT: voltage 250 mV
(phono jacks) impedance 1 kilohms
PHONES: accepts headphones of
(stereo mini jack) 8 ohms or more
SPEAKER
(MHC-DP700)
or FRONT SPEAKER
(MHC-DP800AV)
MHC-DP700 (Central and
South American models): accepts impedance of 6 to
16 ohms
MHC-DP700 (Other
models) and
MHC-DP800AV: accepts impedance of 8 to
16 ohms
REAR SPEAKER: accepts impedance of 8 to
(MHC-DP800AV only) 16 ohms
CENTER SPEAKER: accepts impedance of 8 to
(MHC-DP800AV only) 16 ohms
SUB WOOFER: Voltage 1 V,
impedance 1 kilohms
CD player section
System Compact disc and digital
audio system
Laser Semiconductor laser
(λ=795 nm)
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Signal-to-noise ratio More than 90 dB
Dynamic range More than 90 dB
DIGITAL OUT OPTICAL
(Square optical connector jack, rear panel)
wavelength 660 nm
Tape player section
Recording system 4-track 2-channel stereo
Frequency response 40 – 13,000 Hz (±3 dB),
(DOLBY NR OFF) using Sony TYPE I
cassette,
40 – 14,000 Hz (±3 dB),
using Sony TYPE II
cassette
Wow and flutter ±0.15% W.Peak (IEC)
0.1% W.RMS (NAB)
±0.2% W.Peak (DIN)
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM lead antenna
Antenna terminals 75 ohm unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Pan American model: 530 – 1,710 kHz
(with the interval set at
10 kHz)
531 – 1,710 kHz
(with the interval set at
9 kHz)
European and Middle Eastern models:
531 – 1,602 kHz
(with the interval set at
9 kHz)
Other models: 531 – 1,602 kHz
(with the interval set at
9 kHz)
530 – 1,710 kHz
(with the interval set at
10 kHz)
Antenna AM loop antenna
Antenna terminals External antenna terminal
Intermediate frequency 450 kHz
continued
